UPD720130GC-9EU-SIN Datasheet

  • UPD720130GC-9EU-SIN

  • USB2.0 to IDE Bridge

  • 44頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD720130
USB2.0 to IDE Bridge
The
碌
PD720130 is designed to perform a bridge between USB 2.0 and ATA/ATAPI. The
碌
PD720130 complies
with the Universal Serial Bus Specification Revision 2.0 full-/high-speed signaling and works up to 480 Mbps. The
碌
PD720130 is integrated CISC processor, ATA/ATAPI controller, endpoint controller (EPC), serial interface engine
(SIE), and USB2.0 transceiver into a single chip.
The USB2.0 protocol and class specific protocol (bulk only
protocol) are handled by USB2.0 transceiver, SIE, and EPC. And the transport layer is performed by V30MZ CISC
processor which is in the
碌
PD720130. The software to control the
碌
PD720130 is located in an embedded ROM. In
the future, the
碌
PD720130 will be released to support external Flash Memory / EEPROM鈩?option to update function
by firmware.
Detailed function descriptions are provided in the following user鈥檚 manual. Be sure to read the manual before designing.
碌
PD720130 User鈥檚 Manual: S16412E
FEATURES
鈥?Compliant with Universal Serial Bus Specification Revision 2.0 (Data Rate 12/480 Mbps)
鈥?Compliant with ATA/ATAPI-6 (LBA48, PIO Mode 0-4, Multi Word DMA Mode 0-2, Ultra DMA Mode 0-4)
鈥?USB2.0 high-speed bus powered device capability
鈥?Certified by USB implementers forum and granted with USB 2.0 high-speed Logo (TID :40320125)
鈥?One USB2.0 high-speed transceiver / receiver with full-speed transceiver / receiver
鈥?USB2.0 High-speed or Full-speed packet protocol sequencer (Serial Interface Engine)
鈥?Automatic chirp assertion and full-/high-speed mode change
鈥?USB Reset, Suspend and Resume signaling detection
鈥?Supports power control functionality for IDE device as CD-ROM and HDD
鈥?Supports set feature (TEST_MODE) functionality
鈥?System Clock is generated by 30 MHz X鈥檛al
鈥?2.5 V and 3.3 V power supply
ORDERING INFORMATION
Part Number
Package
100-pin plastic TQFP (fine pitch) (14
脳
14)
100-pin plastic TQFP (fine pitch) (14
脳
14)
碌
PD720130GC-9EU
碌
PD720130GC-9EU-SIN
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. S16302EJ3V0DS00 (3rd edition)
Date Published June 2003 NS CP (K)
Printed in Japan
The mark
shows major revised points.
2002
