UPD65MC Datasheet

  • UPD65MC

  • 4-BIT SINGLE-CHIP MICROCONTROLLER FOR INFRARED REMOTE CONTRO...

  • 64頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD64A, 65
4-BIT SINGLE-CHIP MICROCONTROLLER
FOR INFRARED REMOTE CONTROL TRANSMISSION
DESCRIPTION
Equipped with low-voltage 2.0 V operation, a carrier generation circuit for infrared remote control transmission,
a standby release function through key entry, and a programmable timer, the
碌
PD64A and 65 are suitable for infrared
remote control transmitters.
For the
碌
PD64A and 65, we have made available the one-time PROM product
碌
PD6P5 (under development)
for program evaluation or small-quantity production.
FEATURES
鈥?Program memory (ROM)
鈥?/div>
碌
PD64A : 1002
脳
10 bits
鈥?/div>
碌
PD65 : 2026
脳
10 bits
鈥?Data memory (RAM)
鈥?9-bit programmable timer
鈥?Command execution time
鈥?Stack level
鈥?I/O pins (K
I/O
)
鈥?Input pins (K
I
)
鈥?Sense input pin (S
0
, S
2
)
鈥?S
1
/LED pin (I/O)
鈥?Power supply voltage
鈥?Oscillator frequency
鈥?POC circuit
: 32
脳
4 bits
: 1 channel
: 16
碌
s (when operating at f
X
= 4 MHz: ceramic oscillation)
: 1 level (Stack RAM is for data memory RF as well.)
: 8 units
: 4 units
: 2 units
: 1 unit (When in output mode, this is the remote control transmission display
pin.)
: V
DD
= 2.0 to 3.6 V
: f
X
= 2.4 to 8 MHz
鈥?Operating ambient temperature : T
A
= 鈥?0 to +85
擄C
鈥?Built-in carrier generation circuit for infrared remote control
APPLICATION
Infrared remote control transmitter (for AV and household electric appliances)
Unless otherwise specified, the
碌
PD65 is treated as the representative model throughout this document.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for availability
and additional information.
Document No. U14380EJ2V0DS00 (2nd edition)
Date Published November 1999 N CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1999
