DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD17P709A
4-BIT SINGLE-CHIP MICROCONTROLLER
WITH DEDICATED HARDWARE FOR DIGITAL TUNING SYSTEM
DESCRIPTION
The
碌
PD17P709A is produced by replacing the on-chip mask ROM of the
碌
PD17704A, 17705A, 17707A, 17708A,
and 17709A with a one-time PROM.
The
碌
PD17P709A allows programs to be written once, so the
碌
PD17P709A is suitable for preproduction in
碌
PD17704A, 17705A, 17707A, 17708A, or 17709A system development or low-volume production.
When reading this document, also refer to the publications on the
碌
PD17704A, 17705A, 17707A, 17708A,
or 17709A.
The electrical characteristics (including power supply current) and PLL analog characteristics of the
碌
PD17P709A differ from those of the
碌
PD17704A, 17705A, 17707A, 17708A, and 17709A. In high-volume
application set production, be sure to carefully check these differences.
FEATURES
鈥?/div>
Compatible with the
碌
PD17704A, 17705A, 17707A, 17708A, and 17709A
鈥?/div>
On-chip one-time PROM: 32 KB (16384
脳
16 bits)
鈥?/div>
Supply voltage: V
DD
= 5 V
鹵10%
ORDERING INFORMATION
Part Number
Package
80-pin plastic QFP (14
脳
14)
碌
PD17P709AGC-3B9
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. U15723EJ1V0DS00 (1st edition)
Date Published October 2001 N CP(K)
Printed in Japan
