UPD17P236M1MC-5A4 Datasheet

  • UPD17P236M1MC-5A4

  • 4-BIT SINGLE-CHIP MICROCONTROLLER FOR SMALL GENERAL-PURPOSE ...

  • 251.58KB

  • 32頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD17P236
4-BIT SINGLE-CHIP MICROCONTROLLER
FOR SMALL GENERAL-PURPOSE INFRARED
REMOTE CONTROLLER
The
碌
PD17P236 is a model of the
碌
PD17236 with a one-time PROM instead of an internal mask ROM.
Since the user can write programs to the
碌
PD17P236, it is ideal for experimental production or small-scale
production of the
碌
PD17230, 17231, 17232, 17233, 17234, 17235, or 17236 systems.
When reading this document, also read the documents related to the
碌
PD17230, 17231, 17232, 17233, 17234,
17235, and 17236.
Detailed functions are described in the following user's manual. Read this manual when designing your system.
碌
PD172脳脳 Series User's Manual: U12795E
FEATURES
鈥?Pin compatible with
碌
PD17230, 17231, 17232, 17233, 17234, 17235, and 17236 (except PROM programming
function)
鈥?Carrier generator circuit for infrared remote controller (REM output)
鈥?17K architecture: General-purpose register method
鈥?Program memory (one-time PROM): 32 Kbytes (16,384
脳
16)
鈥?Data memory (RAM): 223
脳
4 bits
鈥?Low-voltage detection circuit
鈥?Input/output of P1A
0
pin, clock selection for carrier generation
碌
PD17P236M1
Input/output of P1A
0
pin
Clock (Rf
X
) selection for carrier generation
Output
Rf
X
= f
X
/2
碌
PD17P236M2
Input
碌
PD17P236M3
Output
Rf
X
= f
X
碌
PD17P236M4
Input
鈥?Supply voltage: V
DD
= 2.2 to 3.6 V (f
X
= 4 MHz: high-speed mode, 4
碌
s)
V
DD
= 3.0 to 3.6 V (f
X
= 8 MHz: high-speed mode, 2
碌
s)
APPLICATIONS
Preset remote controllers, toys, and portable systems
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. U14776EJ1V0DS00 (1st edition)
Date Published June 2000 J CP(K)
Printed in Japan
漏
2000
