UPD17P207GF-001-3B9 Datasheet

  • UPD17P207GF-001-3B9

  • 4-BIT SINGLE-CHIP MICROCONTROLLER WITH LCD CONTROLLER/DRIVER...

  • 236.31KB

  • 32頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD17P207
4-BIT SINGLE-CHIP MICROCONTROLLER WITH LCD CONTROLLER/DRIVER
AND A/D CONVERTER FOR INFRARED REMOTE CONTROL TRANSMITTER
DESCRIPTION
碌
PD17P207 is a variation of
碌
PD17207 and is equipped with a one-time PROM instead of an internal mask
ROM.
碌
PD17P207 is suitable for evaluating program when developing a
碌
PD17201A and 17207 systems because
program can be written by the user.
When reading this document, also refer to the
碌
PD17201A, 17207 documents.
FEATURES
鈥?17K architecture:
General-purpose register format
鈥?Pin-compatible with
碌
PD17201A, 17207
except PROM programming functiom
鈥?Internal one-time PROM: 4096
脳
16 bits
鈥?Supply voltage:
2.5 to 5.5 V (at f
X
= 4 MHz, T
A
= 鈥?0 to +75擄C)
2.4 to 5.5 V (at f
X
= 4 MHz, T
A
= 鈥?0 to +60擄C)
2.0 to 5.5 V (at f
XT
= 32.768 kHz, T
A
= 鈥?0 to +75擄C)
ORDERING
INFORMATION
Package
80-pin plastic QFP (14
脳
20 mm)
80-pin plastic QFP (14
脳
20 mm)
80-pin plastic QFP (14
脳
20 mm)
Part Number
碌
PD17P207GF-001-3B9
碌
PD17P207GF-002-3B9
碌
PD17P207GF-003-3B9
The features of each product is shown in the following table:
When using
碌
PD17P207-001, be sure to connect the resonator to the main clock oscllator circuit and
subclock oscillator circuit.
Item
Pull-up resistor of RESET pin
Main clock oscillator circuit
Subclock oscillator circuit
碌
PD17P207-001
Provided
碌
PD17P207-002
Not provided
Provided
Not provided
碌
PD17P207-003
碌
PD17201A, 17207
Not provided
Provided
On request
(mask option)
碌
PD17P207 is different from
碌
PD17201A, 17207 in some of the electrical characteristics, such as
supply voltage, the operating ambient temperature, and supply current. Therefore, use
碌
PD17P207
only for the system evaluation.
The information in this document is subject to change without notice.
Document No. U11777EJ3V0DS00 (3rd edition)
Previous No. IC-2707A
Date Published November 1996 P
Printed in Japan
The mark
shows major revised points.
漏
1993
