UPD17201AGF Datasheet

  • UPD17201AGF

  • 4-BIT SINGLE-CHIP MICROCONTROLLER WITH LCD CONTROLLER/DRIVER...

  • 501.07KB

  • 120頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
碌
PD17201A, 17207
4-BIT SINGLE-CHIP MICROCONTROLLER WITH
LCD CONTROLLER/DRIVER AND A/D CONVERTER
FOR INFRARED REMOTE CONTROL TRANSMITTERS
MOS INTEGRATED CIRCUIT
DESCRIPTION
The
碌
PD17201A, 17207 is a 4-bit single-chip microcontroller, used for infrared remote control transmitters, which
in-tegrates an LCD controller/driver, A/D converter, and remote controller carrier generator circuit on a single chip.
For the CPU, this microcontroller employs the 17K architecture of the general-purpose register method, and it can
directly execute operations between data memory addresses which would have been conventionally executed by an
accumulator. In addition, all the instructions are 16-bit, 1-word instructions, enabling efficient programming.
A one-time PROM model,
碌
PD17P207, to which data can be written only once is also available. This one-time
PROM model is useful for program evaluation of the
碌
PD17201A or 17207.
Detalied functionins are described in the following manual. Be sure to read this manual when designing
your system.
碌
PD172xx Subseries User鈥檚 Manual: IEU-1317
FEATURES
鈥?17K architecture
鈥?Program memory (ROM)
鈥?Data memory (RAM)
鈥?LCD controller/driver
路 Common pins
路 Segment pins
: General-purpose register method
: 3072 x 16 bits (
碌
PD17201A)
4096 x 16 bits (
碌
PD17207)
: 336 x 4 bits (including LCD register 36
脳
4 bits)
: Up to 136 segments can be displayed
: 4 (2 can be used as segment pins)
: 34
resistor
鈥?8-bit A/D converter
鈥?8-bit timer
鈥?Watch timer/watchdog timer
鈥?3-line serial interface
鈥?External interrupt pin (INT)
鈥?I/O pin
鈥?Instruction execution time
鈥?Supply voltage
: 4 channels (successive approximation method in software)
: 1 channel
: 1 channel (WDOUT output)
: 1 channel
: 1
: 20 (including INT)
: 4
碌
s (main clock: f
X
= 4 MHz)
488
碌
s (subclock: f
XT
= 32.768 kHz)
: V
DD
= 2.2 to 5.5 V (main clock : f
X
= 4 MHz)
: V
DD
= 2.0 to 5.5 V (subclock
: f
XT
= 32.768 kHz)
鈥?Infrared remote controller carrier generator (REM output)
路 Voltage booster circuit for driving LCD : LCD drive voltage can be adjusted from 2.4 to 5.4 V with external
Unless otherwise specified, the
碌
PD17207 is treated as the representative model throughout this documents.
The information in this document is subject to change without notice.
Document No. U11778EJ5V0DS00 (5th edition)
(Previous No. IC-2773)
Date Published November 1996 P
Printed in Japan
The mark
shows major revised points.
漏
1991
