DATA SHEET

BIPOLAR ANALOG INTEGRATED CIRCUITS

碌

PC8190K,

碌

PC8191K

RX/TX-IF SiMMIC FOR W-CDMA

DESCRIPTION

The

碌

PC8190K and

碌

PC8191K are silicon monolithic integrated circuit designed as receiver (RX) and transmitter

(TX) IF section for W-CDMA. The

碌

PC8190K is a RX-IF IC including IF-AGC amplifier and demodulator. The

碌

PC8191K is a TX-IF IC including IF-AGC amplifier and quadrature modulator. These two ICs are suitable for kit-use

for W-CDMA IF section.

The ICs are developed using NEC鈥檚 new ultra high speed silicon bipolar process.

FEATURES

鈥?RX-IF: 380 MHz, TX-IF: 570 MHz

鈥?Low power consumption

鈥?Built-in power saving function

鈥?Small size: 20-pin plastic QFN package (3.2

脳

4.2

脳

0.8 mm)

APPLICAION

鈥?W-CDMA

ORDERING INFORMATION

Part Number

Package

20-pin plastic QFN

(3.2

脳

4.2

脳

0.8 mm)

Supplying Form

鈥?Embossed tape 12 mm wide.

鈥?Pin 1 indicates pull-out direction of tape

鈥?Qty 2.5 kpcs/reel

碌

PC8190K-E1

碌

PC8191K-E1

Remark

To order evaluation samples, please contact your local NEC sales office.

Part number for sample order:

碌

PC8190K,

碌

PC8191K

Caution electro-static sensitive devices.

The information in this document is subject to change without notice. Before using this document, please

confirm that this is the latest version.

Not all devices/types available in every country. Please check with local NEC representative for

availability and additional information.

Document No. P15669EJ2V0DS00 (2nd edition)

Date Published August 2001 NS CP(K)

Printed in Japan

漏

2001

制造商
NEC
類型
RF IC's
封裝 / 箱體
QFN-20
工作頻率
570 MHz
安裝風格
SMD/SMT
工作電源電壓
2.7 V to 3.3 V
