UPC1694GR-E1 Datasheet

  • UPC1694GR-E1

  • GENERAL PURPOSE HIGH FREQUENCY WIDEBAND IC FOR FREQUENCY DOW...

  • 20頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
碌
PC1694GR
GENERAL PURPOSE HIGH FREQUENCY WIDEBAND IC
FOR FREQUENCY DOWN-CONVERTER
DESCRIPTION
The
碌
PC1694GR is Silicon monolithic IC for down-converter that is capable of operating up to 1 GHz.
This IC consists of double balanced mixer (DBM), local oscillator and IF amplifier. Furthermore, combination with
the
碌
PC1663G (high-speed video amp) enables it to be applied to a FM demodulation circuit such as DBS tuner.
The package is 14-pin SOP suitable for surface mounting.
FEATURES
鈥?Satisfactory 1% cross-modulation distortion characteristics: CM = 103 dB
碌
@ f
des
= 200 MHz
鈥?Wide band operation: f
鈮?/div>
1 GHz
鈥?Easy to connect with varactor diode due to balanced amplifier oscillator
鈥?Single-end push-pull IF amplifier suppresses fluctuation in output impedance
鈥?Supply voltage: 5 V
鈥?Packaged in 14-pin SOP suitable for smaller mounting area
APPLICATIONS
鈥?Tuners for TV and VCR
ORDERING INFORMATION
Part Number
Package
14-pin plastic SOP (225 mil)
Supplying Form
Embossed tape 16 mm wide.
Pin 1 indicates pull-out direction of tape.
碌
PC1694GR-E1
Remark
To order evaluation samples, please contact your local NEC office.
(Part number for sample order:
碌
PC1694GR)
Caution Electro-static sensitive devices
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. P12965EJ3V0DS00 (3rd edition)
Date Published October 1999 N CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1997, 1999
