DATA SHEET
BIPOLAR DIGITAL INTEGRATED CIRCUITS
碌
PB1502GR,
1502GR(1)
1.7 GHz/ 2.0 GHz LOW-POWER TWO-MODULUS PRESCALER
DIVIDED-BY-64/65, 128/129
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High toggle frequency 鈥?2.0 GHz:
碌
PB1502GR(1), 1.7 GHz:
碌
PB1502GR
Low power consumption 鈥?6.7 mA TYP. at 3 V
Operating supply voltage 鈥?2.7 V to 3.3 V
High input sensitivity 鈥?130 to 220 mV
P-P
:
碌
PB1502GR(1), 100 to 320 mV
P-P
:
碌
PB1502GR (@50
鈩?
Equipped with power-save function: 5
碌
A (standard) on power-save mode.
Packaged in 8 pins plastic SOP suitable for surface mounting.
DESCRIPTION
碌
PB1502GR and
碌
PB1502GR(1) are two-modulus prescaler divided by 64/65 or 128/129. This device is designed for
mobile communication applications for example 0.8-1.9 GHz cellular and cordless telephones. The ICs operate on low power
and therefore are suitable for hand-held, battery-operated systems.
These products are manufactured using NEC鈥檚 20 GHz f
T
NESAT鈩?/div>
III
silicon bipolar process. This process uses silicon
nitride passivation film and gold metallization wirings. These materials can protect the chips from external pollution and
prevent corrosion and migration. Thus, these products have excellent performance, uniformity and reliability.
ORDER INFORMATION
ORDER NUMBER
PACKAGE
8 pin plastic SOP
(225 mil)
SUPPLYING FORM
Embossed tape 12 mm wide. QTY 2.5 k/reel
Pin1 is in tape pull-out direction.
f
in
MAX.
1.7 GHz
2.0 GHz
碌
PB1502GR鈥揈1
碌
PB1502GR(1)鈥揈1
Remarks
To order evaluation samples, please contact your local NEC sales office. (Order number:
碌
PB1502GR,
碌
PB1502GR(1))
Caution electro-static sensitive devices
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for availability
and additional information.
Document No. P10871EJ3V0DS00 (3rd edition)
Date Published October 1999 N CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1996, 1999
