UCC3305 Datasheet

  • UCC3305

  • HID Lamp Controller

  • 9頁

  • TI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

application
INFO
available
UCC2305
UCC3305
HID Lamp Controller
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Regulates Lamp Power
Compensates For Lamp
Temperature
Fixed Frequency Operation
Current Mode Control
Overcurrent Protected
Overvoltage Shutdown
Open and Short Protected
High Current FET Drive Output
Operates Over Wide Battery
Voltage Range: 5V to 18V
DESCRIPTION
The UCC3305 integrates all of the functions required to control and drive one
HID lamp. The UCC3305 is tailored to the demanding, fast turn-on requirements
of automobile headlamps, but is also applicable to all other lighting applications
where HID lamps are selected. HID lamps are ideal for any lighting applications
that can benefit from very high efficiency, blue-white light color, small physical
lamp size, and very long life.
The UCC3305 contains a complete current mode pulse width modulator, a lamp
power regulator, lamp temperature compensation, and total fault protection.
Lamp temperature compensation is critical for automobile headlamps, because
without compensation, light output varies dramatically from a cold lamp to one
that is fully warmed up.
The UCC2305 is tested for full performance with ambient temperature
from 鈥?0擄C to +105擄C while the UCC3305 is tested with ambient temperature
from 0擄C to +70擄C. The UCC3305 is available in a 28 pin small-outline, surface
mount plastic package (SOIC).
BLOCK DIAGRAM
UDG-94091-1
SLUS297B - SEPTEMBER 1995 - REVISED APRIL 2004
