TS3V393C,I,M

MICROPOWER DUAL CMOS VOLTAGE COMPARATORS

DEDICATED TO

3.3V

BATTERY

SUPPLY

(specified at 3V and 5V)

EXTREMELY LOW SUPPLY CURRENT :

9碌A(chǔ) typ / comparator

WIDE SINGLE SUPPLY RANGE

2.7V TO 16V

EXTREMELY LOW INPUT CURRENT:

1pA typ

DIP8

(Plastic Package)

INPUT COMMON-MODE VOLTAGE RANGE

INCLUDES GND

FAST RESPONSE TIME : 2.5碌s typ for

5mV overdrive

PIN-TO-PIN AND FUNCTIONALLY

COMPATIBLE WITH BIPOLAR LM393

DESCRIPTION

The TS3V393 is a micropower dual CMOS dual

voltage comparator with extremely low consump-

tion of 9碌A(chǔ) typ / comparator (20 times less than

bipolar LM393). Similar performances are offered

by the dual micropower comparator TS3V3702

with a push-pull CMOS output.

Thus response times remain similar to the LM393.

ORDER CODE

Part Number

TS3V393I

Temperature

Range

-40擄C, +125擄C

Package

鈥?/div>

Output 1

InvertingInput 1

Non-invertingInput 1

SO8

(Plastic Micropackage)

TSSOP8

(Thin Shrink Small Outline Package)

PIN CONNECTIONS

(top view)

Output2

InvertingInput 2

Non-invertingInput 2

N =

Dual in Line Package (DIP)

D =

Small Outline Package (SO) - also available in Tape & Reel (DT)

P =

Thin Shrink Small Outline Package (TSSOP) - only available

in Tape & Reel (PT)

January 2002

1/7
