TS391IL Datasheet

  • TS391IL

  • LOWPOWER SINGLE VOLTAGE COMPARATORS

  • 47.74KB

  • 5頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

廬
TS391
LOW POWER SINGLE VOLTAGE COMPARATORS
.
.
.
.
.
.
.
.
.
WIDE SINGLE SUPPLY VOLTAGE RANGE OR
DUAL SUPPLIES +2V TO +36V OR
鹵1V
TO
鹵18V
VERY LOW SUPPLY CURRENT (0.2mA)
INDEPENDENT OF SUPPLY VOLTAGE
(1 mW/comparator at +5V)
LOW INPUT BIAS CURRENT : 25nA TYP
LOW INPUT OFFSET CURRENT :
鹵5nA
TYP
LOW INPUT OFFSET VOLTAGE :
鹵1mV
TYP
INPUT COMMON-MODE VOLTAGE RANGE
INCLUDES GROUND
LOW OUTPUT SATURATION VOLTAGE :
250mV TYP. (I
O
= 4mA)
DIFFERENTIAL INPUT VOLTAGE RANGE
EQUAL TO THE SUPPLY VOLTAGE
TTL, DTL, ECL, MOS, CMOS COMPATIBLE
OUTPUTS
L
SOT23-5L
(Tiny Package)
DESCRIPTION
These devices consist of a low power voltage com-
parator designed specifically to operate from a sin-
gle supply over a wide range of voltages. Operation
from split power supplies is also possible.
This comparator also has a unique characteristic in
that the input common-mode voltage range
includes ground eventhough operatedfrom a single
power supply voltage.
PIN CONNECTIONS
(top view)
ORDER CODES
Part
Number
TS391IL
Example :
TS391IL
Temperature
Range
鈥?0, +125 C
o
Package
L
鈥?/div>
Output
1
5
+
V
CC
V
CC
-
2
Inve rting input
3
4
Non-inve rting input
November 1998
1/5
