TS339C,I,M
MICROPOWER QUAD CMOS VOLTAGE COMPARATORS
s
EXTREMELY LOW SUPPLY CURRENT :
9碌A
typ / comparator
s
WIDE SINGLE SUPPLY RANGE
3V TO 16V
OR DUAL SUPPLIES (鹵1.5V TO
鹵8V)
1pA typ
s
EXTREMELY LOW INPUT BIAS CURRENT :
s
EXTREMELY LOW INPUT OFFSET CUR-
RENT :
1pA typ
N
DIP14
(Plastic Package)
s
INPUT COMMON-MODE VOLTAGE RANGE
INCLUDES GND
s
HIGH INPUT IMPEDANCE : 10
12
鈩?/div>
typ
s
FAST RESPONSE TIME : 1.5碌s typ for 5mV
overdrive
D
SO14
(Plastic Micropackage)
s
PIN-TO-PIN AND FUNCTIONALLY COMPATI-
BLE WITH BIPOLAR LM339
DESCRIPTION
The TS339 is a micropower CMOS quad voltage
comparator with extremely low consumption of
9碌A typ / comparator (20 times less than bipolar
LM339). Similar performances are offered by the
quad micropower comparator TS3704 with a
push-pull CMOS output.
Thus response times remain similar to the LM339.
ORDER CODE
Output 2
P
TSSOP14
(Thin Shrink Small Outline Package)
PIN CONNECTIONS
(top view)
1
14
13
12
-
+
-
+
+
-
+
-
11
10
9
8
Output 3
Output 4
V
CC
-
Non-invertingInput 4
Inverting Input 4
Non-invertingInput 3
Inverting Input 3
Part
Number
TS339C
TS339I
TS339M
Temperature
Range
0擄C, +70擄C
-40擄C, +125擄C
-55擄C, +125擄C
Package
N
鈥?/div>
鈥?/div>
鈥?/div>
D
鈥?/div>
鈥?/div>
鈥?/div>
P
鈥?/div>
鈥?/div>
鈥?/div>
Output1 2
V
CC
+
3
Inverting Input 1 4
Non-inverting Input 1 5
Inverting Input 2
Non-invertingInput 2
6
7
N =
Dual in Line Package (DIP)
D =
Small Outline Package (SO) - also available in Tape & Reel (DT)
P =
Thin Shrink Small Outline Package (TSSOP) - only available
in Tape & Reel (PT)
January 2002
1/6
