TS258
Dual Operating Amplifier
Pin assignment:
1. Output
2. Input A (-)
3. Input A (+)
4. Gnd
5. Input B (+)
6. Input B (-)
7. Output B
8. Vcc
Supply Voltage Range 3 V to 32V
Dual Channel Amplifier
General Description
Utilizing the circuit designs perfected for recently introduced Quad Operational Amplifiers, these dual operational
amplifiers have several distinct advantages over standard operational amplifier types in single supply applications. They
can operate at supply voltages as low as 3.0 Volts or as high as 32 Volts with quiescent currents about one fifth of those
associated with the LM741 (on a pet amplifier basis). The common mode input range includes the negative supply,
thereby eliminating the necessity for external biasing components in many applications.
The TS258 is equivalent to one half of TS224, and output voltage range also includes the negative supply voltage.
The TS258 is offered in 8 pin SOP-8 and DIP-8 package.
Features
Short circuit protected outputs
True differential input stage
Single supply operation: 3V to 32V
Low input bias currents
Internally compensated
Common mode range extends to negative supply
Single and split supply operation
Similar performance to the popular MC1558
Block Diagram
Ordering Information
Part No.
TS258CD
TS258CS
Operating Temp.
o
-40 ~ +85 C
Package
DIP-8
SOP-8
Absolute Maximum Rating
Supply Voltage
Differential Input Voltage (note 1)
Input Common Mode Voltage Range (note 2)
Input Forward Current (note 3)
Output Short Circuit Duration
Power Dissipation @ Ta=25
o
C
o
Derate above 25 C
Vcc, Vcc/Vee
V
IDR
V
ICR
Iif
Isc
1/R胃ja
T
J
T
STG
+32 or 鹵16
32
-0.3 to 32
50
Continuous
570
5.7
0 ~ +125
-65 ~ +150
Vdc
Vdc
Vdc
mA
mA
mW
mW/
o
C
o
o
Operating Junction Temperature Range
Storage Temperature Range
C
C
NOTE :
1. Split Power Supplies.
2. For supply. Voltages less than 32V for the PJ358 the absolute maximum input voltage is equal to the supply voltage.
3. This input current will only exist when the voltage is negative at any of the input leads. Normal output states will
reestablish when the input voltage returns to a voltage greater than -0.3V.
