TS1874AIDT Datasheet

  • TS1874AIDT

  • Voltage-Feedback Operational Amplifier

  • 20頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TS1871
TS1872
TS1874
1.8V
INPUT/OUTPUT
RAIL TO RAIL
LOW POWER
OPERATIONAL AMPLIFIERS
s
OPERATING AT
V
CC
= 1.8V to 6V
s
RAIL TO RAIL
INPUT & OUTPUT
s
EXTENDED Vicm
(V
DD
- 0.2V to V
CC
+ 0.2V)
s
LOW SUPPLY CURRENT
(400碌A(chǔ))
s
GAIN BANDWIDTH PRODUCT
(1.6MHz)
s
HIGH STABILITY
s
ESD TOLERANCE
(2kV)
s
LATCH-UP IMMUNITY
s
AVAILABLE IN
SOT23-5 MICROPACKAGE
DESCRIPTION
The TS187x (Single, Dual & Quad) is operational
amplifier able to operate with voltages as low as
1.8V and features both I/O Rail to Rail.
The common mode input voltage extends 200mV
@ 25擄C beyond the supply voltages while the out-
put voltage swing is within 100mV of each Rail for
a 600 Ohm load resistor. This I/O Rail to Rail con-
figuration gives the chance to the user to have the
entire supply voltage range available. Offering
20mA min., 65mA typ. value and exhibiting an ex-
cellent speed-power ratio, 1.6MHz GBP & 400碌A(chǔ)
supply current, this Op-Amp is very well-suited for
battery-supplied and portable applications.
Stability and minimum overshoot with capacitive
loads is maintained by 53擄 typ. of phase margin
with 100pF load capacitor @ 1.8V.
APPLICATION
TS1871ID-TS1871IDT
PIN CONNECTIONS
(top view)
TS1871ILT
Output
VDD
Non Inverting Input
1
2
3
+ -
5
VCC
4
Inverting Input
N.C.
Inverting Input
Non Inverting Input
VDD
1
2
3
4
_
+
8
7
6
5
N.C.
VCC
Output
N.C.
TS1872IN-TS1872ID-TS1872IDT-TS1872IPT
utput1 1
O
InvertingInput 1 2
NonInvertingInput 1 3
VD 4
D
_
+
8 VCC
7 Output 2
_ 6 Invertin
gInput 2
+ 5 NonInvertingInput 2
s
Battery-powered applications (Toys)
s
Portable communication devices (cell phone)
s
Audio driver (Headphone Driver)
s
Laptop/Notebook computers
ORDER CODE
Part
Number
TS1871I/AI
TS1872I/AI
TS1874I/AI
Temperature
Range
Package
N
鈥?/div>
鈥?/div>
D
鈥?/div>
鈥?/div>
鈥?/div>
P
鈥?/div>
鈥?/div>
L
鈥?/div>
SOT23
Marking
K161/K162
TS1874IN-TS1874ID-TS1874IDT-TS1874IPT
Output1 1
Inverting Input1 2
Non Inverting Input 1 3
VCC
Non Inverting Input 2
4
5
+
_
_
+
14 Output 4
_ 13 Inverting Input 4
+ 12 Non InvertingInput 4
11 VDD
+ 10 NonInverting Input 3
_
9 Inverting Input 3
8 Output 3
-40, +125擄C
N =
Dual in Line Package (DIP)
D =
Small Outline Package (SO) - also available in Tape & Reel (DT)
P =
Thin Shrink Small Outline Package (TSSOP) - only available
in Tape & Reel (PT)
L =
Tiny Package (SOT23-5) - only available in Tape & Reel (LT)
Inverting Input 2 6
Output 2 7
August 2001
1/20

TS1874AIDT 產品屬性

  • TS1874A View All Specifications

  • 1

  • 集成電路 (IC)

  • Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

  • -

  • 通用

  • 4

  • 滿擺幅

  • 0.6 V/µs

  • 1.8MHz

  • -

  • 70nA

  • 100µV

  • 500µA

  • 80mA

  • 1.8 V ~ 6 V

  • -40°C ~ 125°C

  • 表面貼裝

  • 14-SOIC（0.154"，3.90mm 寬）

  • 14-SO

  • Digi-Reel®

  • 497-4542-6
