TS1117B
800mA Low Dropout Positive Voltage Regulator
Pin assignment:
1. Gnd/Adj 8.N/C
2. 3. Out 6. 7. Out
4. Input
5. N/C
Pin assignment:
1. Gnd/Adj
2. Output
3. Input
Low Dropout Voltage 1.3V max.
General Description
The TS1117B Series are high performance positive voltage regulators are designed for use in applications requiring low
dropout performance at full rated current, Additionally, the TS1117B Series provides excellent regulation over variations
due to changes in line, load and temperature. Outstanding features include low dropout performance at rated current, fast
transient response, internal current limiting and thermal shutdown protection of the output device. The TS1117B Series
are three terminal regulators with fixed and adjustable voltage options available in popular packages.
This series is offered in 3-pin TO-252 SOT-223 and 8-pin SOP package.
Features
Low dropout performance 1.3V max.
Full current rating over line and temperature.
Fast transient response
鹵2%Total
output regulation over line, load and
temperature
Adjust pin current 90uA (typ.)
Line regulation typical 0.015%.
Load regulation typical 0.05%.
Fixed/adjustable output voltage
TO-252 SOT-223 and SOP-8 package
Block Diagram
Ordering Information
Part No.
TS1117BCS
xx
TS1117BCP
xx
-20 ~ +85
o
C
Operating Temp.
(Junction)
Package
SOP-8
TO-252
TS1117BCW
xx
SOT-223
Note: Where
xx
denotes voltage option,
50=
5.0V
33=
3.3V
25=
2.5V
18=
1.8V
Leave blank for adjustable version.
Absolute Maximum Rating
Input Supply Voltage
Operation Input Supply Voltage
Power Dissipation
Operating Junction Temperature Range
Storage Temperature Range
Lead Soldering Temperature (260 C)
o
Vin
Vin (opt. Typ.)
P
D
T
J
T
STG
15
12
Internally Limited
-20 ~ +125
-65 ~ +150
5
V
V
W
o
o
C
C
S
TS1117B
1-6
2003/12 rev. D
