EIA-RS481 (equivalent to IEC 286, Part 3).
鈥?/div>
Fuses are orientated in embossed pockets with ceramic
side facing up to facilitate proper mounting (See 鈥淓lectrical
Characteristics鈥? General Note 4).
3216LV
Product
Symbol
(See Table)
Rated Current
Package Code
TR
= 3,000 pieces on tape on a 178mm reel.
TR1
= 15,000 pieces on tape on a 330mm reel.
SP
= 50 pieces on tape in a plastic box.
Contact Bussmann if other package quantities are required.
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 VAC, 75-1500 VDC). Refer to BIF document #8002 or contact
Bussmann Application Engineering at 314-527-1270 for more information.
Electrical Characteristics
Part Number
Current
Rating
(Ampere)
Mark
Appearing
On Part
Typical Melting
Integral @ 50A
(A
2
* sec)
Typical Total
Clearing Integral
@ 50A (A
2
* sec)
AC
.00017
.0010
.0016
.0033
.022
.038
.044
DC
.0001
.0009
.0026
.0042
.0098
.027
.033
Typ. Resistance Typ. Voltage
@
虜
10% Rated Drop @ Rated
Current (Ohms) Current (Volts)
4.50
1.80
1.15
.75
.52
.40
.26
1.4
.73
.66
.63
.63
.62
.49
(XX=Package Code)
AC
DC
XX/3216LV-250mA
.250
.25
.00016
.000084
XX/3216LV-375mA
.375
White Dot
.001
.0002
XX/3216LV-500mA
.500
0.5
.0014
.0019
XX/3216LV-750mA
.750
.75
.0033
.00095
XX/3216LV-1A
1
1
.020
.0084
XX/3216LV-1.25A
1.25
White
脝
.035
.021
XX/3216LV-1.5A
1.5
1.5
.038
.024
General Notes:
1.
AC interrupting rating, melting integral and total clearing integral measured at 125V, unity power factor.
2.
DC interrupting rating, melting integral and total clearing integral measured at 125V with a battery source.
3.
Voltage drop measured at 23 鹵 3擄C ambient temperature with the device mounted on a suitable circuit board trace.
4.
It is recommended that fuses be mounted with ceramic (white) side facing up.
5.
Device designed to carry rated current for four hours minimum. An operating current of 80% or less of rated current is
with further derating required at elevated ambient temperatures.
6.
Contact Bussmann if higher ampere ratings are needed.
recommended,
12-16-98
SB98107 Rev. A
Form No. 3216LV
Page 1 of 2
BIF Doc #3006
