TMS320F243, TMS320F241

DSP CONTROLLERS

SPRS064B 鈥?DECEMBER 1997 鈥?REVISED FEBRUARY 1999

High-Performance Static CMOS Technology

Includes the T320C2xx Core CPU

鈥?Object-Compatible With the TMS320C2xx

鈥?Source-Code-Compatible With

TMS320C25

鈥?Upwardly Compatible With TMS320C5x

鈥?50-ns Instruction Cycle Time

Commercial and Industrial Temperature

Available

Memory

鈥?544 Words x 16 Bits of On-Chip

Data/Program Dual-Access RAM

(DARAM)

鈥?8K Words x 16 Bits of Flash EEPROM

鈥?224K Words x 16 Bits of Total Memory

Address Reach (鈥橣243 only)

External Memory Interface (鈥橣243 only)

Event-Manager Module

鈥?Eight Compare/ Pulse-Width Modulation

(PWM) Channels

鈥?Two 16-Bit General-Purpose Timers With

Six Modes, Including Continuous Up and

Up / Down Counting

鈥?Three 16-Bit Full Compare Units With

Deadband

鈥?Three Capture Units (Two With

Quadrature Encoder-Pulse Interface

Capability)

Single 10-Bit Analog-to-Digital Converter

(ADC) Module With 8 Multiplexed Input

Channels

Controller Area Network

(CAN) Module

26 Individually Programmable, Multiplexed

General-Purpose I / O (GPIO) Pins

Six Dedicated GPIO Pins (鈥橣243 only)

Phase-Locked-Loop (PLL)-Based Clock

Module

Watchdog (WD) Timer Module

Serial Communications Interface (SCI)

Module

16-Bit Serial Peripheral Interface (SPI)

Module

Five External Interrupts (Power Drive

Protection, Reset, NMI, and Two Maskable

Interrupts)

Three Power-Down Modes for Low-Power

Operation

Scan-Based Emulation

Development Tools Available:

鈥?Texas Instruments (TI鈩? ANSI C

Compiler, Assembler / Linker, and

C-Source Debugger

鈥?Full Range of Emulation Products

鈥?Self-Emulation (XDS510鈩?

鈥?Third-Party Digital Motor Control and

Fuzzy-Logic Development Support

144-Pin QFP PGE Package (鈥橣243)

68-Pin PLCC FN Package (鈥橣241)

64-Pin QFP PG Package (鈥橣241)

description

The TMS320F243 and TMS320F241 devices are members of the 鈥?4x family of digital signal processor (DSP)

controllers based on the TMS320C2xx generation of 16-bit fixed-point DSPs. The 鈥橣243 is a superset of the

鈥橣241. These two devices share similar core and peripherals with some exceptions. For example, the 鈥橣241

does not have an external memory interface. This new family is optimized for digital motor / motion control

applications. The DSP controllers combine the enhanced TMS320 architectural design of the 鈥機2xx core CPU

for low-cost, high-performance processing capabilities and several advanced peripherals optimized for

motor / motion control applications. These peripherals include the event manager module, which provides

general-purpose timers and PWM registers to generate PWM outputs, and a single,10-bit analog-to-digital

converter (ADC), which can perform conversion within 1

碌s.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

TI and XDS510 are trademarks of Texas Instruments Incorporated.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of Texas Instruments

standard warranty. Production processing does not necessarily include

testing of all parameters.

漏

1999, Texas Instruments Incorporated
