TK15408MTL/408 Datasheet

  • TK15408MTL/408

  • 75 OHM VIDEO LINE DRIVER

  • 8頁

  • TOKO   TOKO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TK15408
75
鈩?/div>
VIDEO LINE DRIVER
FEATURES
s
Fixed Gain (6 dB)
s
Internal 75
鈩?/div>
Drivers
s
Very Small Output Capacitor Using SAG Function Pin
s
Internal Clamping Circuit
s
Single +5 V Power Supply Operation
APPLICATIONS
s
s
s
s
s
s
Video Equipment
Digital Cameras
CCD Cameras
TV Monitors
Video Tape Recorders
LCD Projectors
DESCRIPTION
Operating from a single +5 V supply, the TK15408 is a dual
video driver IC that takes standard video signals as analog
inputs and provides buffered analog outputs for driving
150
鈩?/div>
loads (series 75
鈩?/div>
resistor and 75
鈩?/div>
cable load).
Both amplifiers have a fixed gain of 6 dB with internal
clamping circuits. Each input is clamped at 1.29 V and
amplified 6 dB to produce 2 V
P-P
(typical) into a series
75
鈩?/div>
resistor and 75
鈩?/div>
cable load. The internal 1.5 k SAG
function resistors provide gain compensation for low
frequency signals. Nominal power dissipation (no input) is
typically 76 mW. The TK15408 is ideally suited for S-VHS
systems.
The TK15408M is available in the very small SOT23L-8
surface mount package.
TK15408
SAG_A
OUTPUT_A
INPUT_A
01S
VCC
GND
INPUT_B
SAG_B
OUTPUT_B
BLOCK DIAGRAM
5 k鈩?/div>
-
75
鈩?/div>
Driver
5 k鈩?/div>
1.5 k鈩?/div>
VCC
+
ORDERING INFORMATION
TK15408M
Tape/Reel Code
5 k鈩?/div>
TAPE/REEL CODE
TL: Tape Left
December 1999 TOKO, Inc.
+
75
鈩?/div>
Driver
-
5 k鈩?/div>
1.5 k鈩?/div>
Page 1
