TK15407MTL/407 Datasheet

  • TK15407MTL/407

  • 75 OHM VIDEO LINE DRIVER

  • 70.16KB

  • 8頁

  • TOKO   TOKO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TK15407
75
鈩?/div>
VIDEO LINE DRIVER
FEATURES
s
Fixed Gain (6 dB)
s
Internal 75
鈩?/div>
Drivers
s
Very Small Output Capacitor Using SAG Function Pin
s
Active High ON/OFF Control
s
Very Low Standby Current (typ. I
STBY
鈮?/div>
25
碌
A)
s
Very Small SOT23L-8 Package
APPLICATIONS
s
s
s
s
s
s
Video Equipment
Digital Cameras
CCD Cameras
TV Monitors
Video Tape Recorders
LCD Projectors
DESCRIPTION
Operating from a single +5 V supply, the TK15407 is a dual
video driver IC that takes standard video signals as analog
inputs and provides buffered analog outputs for driving
150
鈩?/div>
loads (series 75
鈩?/div>
resistor and 75
鈩?/div>
cable load).
Both amplifiers have a fixed gain of 6 dB and can be used
in series for 12 dB gain. The luminance (Y) input is
clamped at 1.29 V and amplified 6 dB to produce 2 V
P-P
(typical) into a series 75
鈩?/div>
resistor and 75
鈩?/div>
cable load.
The internal 1.5 k SAG function resistor provides gain
compensation for low frequency signals. The chromanance
(C) input is biased at 2.6 V and amplified 6 dB to produce
1.1 V
P-P
(typical) into a series 75
鈩?/div>
resistor and 75
鈩?/div>
cable
load. During standby (Pin 3 grounded), the TK15407
consumes only 119
碌W
of power. Nominal power
dissipation (no input) is typically 76 mW. The TK15407 is
ideally suited for S-VHS systems.
The TK15407M is available in the very small SOT23L-8
surface mount package.
TK15407
SAG_Y
OUTPUT_Y
INPUT_Y
01S
VCC
GND
STANDBY
INPUT_C
OUTPUT_C
BLOCK DIAGRAM
5 k鈩?/div>
-
5 k鈩?/div>
1.5 k鈩?/div>
+
TK15407M
Tape/Reel Code
5 k鈩?/div>
TAPE/REEL CODE
TL: Tape Left
January 2000 TOKO, Inc.
-
ORDERING INFORMATION
+
100 k鈩?/div>
5 k鈩?/div>
VCC
Page 1
