TK15329MTL/329 Datasheet

  • TK15329MTL/329

  • Audio Analog Switch

  • 213.50KB

  • 16頁

  • TOKO   TOKO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TK15329
Audio Analog Switch
FEATURES
s
s
s
s
s
s
Wide Operating Voltage Range (2 to 14 V)
Low Distortion (typ. 0.004%)
Wide Dynamic Range (typ. 6 V
P-P
)
Low Output Impedance (typ. 20
鈩?/div>
)
Low Switching Noise (typ. 3 mV)
Output Parallel Connection Possible
APPLICATIONS
s
Audio Systems
s
Radio Cassettes
DESCRIPTION
The TK15329M is an Analog Switch IC that was developed
for audio frequency. The function is to select one output
from two inputs and has a floating position too. The
channel can be changed by two control levels and the
device includes two circuits. The TK15329M has a
mono-power supply and the input bias is a supply type
from outside. Because the distortion is very low, the
TK15329M fits various signals switching. It is best suited
for Hi-Fi devices. Operating voltage is wide, the circuit
plan is simple. The TK15329M is available in a small
plastic surface mount package (SSOP-12).
TK15329
VCC
Bch
OUT
1ch-in
Ach
1KEY
NC
GND
11 Bch
10 OUT
9
8
7
Ach
2 KEY
NC
2ch-in
BLOCK DIAGRAM
VCC
Ach
+
-
1 ch out
1ch-in
2 ch out
1KEY
Bch
+
-
ORDERING INFORMATION
Ach
+
-
Logic
2KEY
TK15329M
Tape/Reel Code
2ch-in
Bch
+
-
GND
TAPE/REEL CODE
TL: Tape Left
June 1999 TOKO, Inc.
Page 1
