THS1207IDA Datasheet

  • THS1207IDA

  • 12 bit 4 ANALOG INPUT 6 MSPS SIMULTANEOUS SAMPLING

  • 33頁

  • TI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

www.ti.com
THS1207
SLAS284A 鈥?AUGUST 2000 鈥?REVISED DECEMBER 2002
12 BIT 4 ANALOG INPUT, 6 MSPS, SIMULTANEOUS SAMPLING
ANALOG TO DIGITAL CONVERTER
FEATURES
D
Simultaneous Sampling of 4 Single-Ended
Signals or 2 Differential Signals or
Combination of Both
to program the ADC into the desired mode. The
THS1207 consists of four analog inputs, which are
sampled simultaneously. These inputs can be selected
individually and configured to single-ended or
differential-inputs. Internal reference voltages for the
ADC (1.5 V and 3.5 V) are provided. An external
reference can also be chosen to suit the dc accuracy
and temperature drift requirements of the application.
The THS1207C is characterized for operation from 0擄C
to 70擄C, the THS1207I is characterized for operation
from 鈥?0擄C to 85擄C.
DA PACKAGE
(TOP VIEW)
D
Signal-to-Noise and Distortion Ratio:
D
D
D
D
D
D
D
D
68 dB at f
I
= 2 MHz
Differential Nonlinearity Error:
鹵1
LSB
Integral Nonlinearity Error:
鹵1.5
LSB
Auto-Scan Mode for 2, 3, or 4 Inputs
3-V or 5-V Digital Interface Compatible
Low Power: 216 mW Max at 5 V
Power Down: 1 mW Max
5-V Analog Single Supply Operation
Internal Voltage References
. . .
50 PPM/擄C
and
鹵5%
Accuracy
D
Glueless DSP Interface
D
Parallel
碌C/DSP
Interface
APPLICATIONS
D
Radar Applications
D
Communications
D
Control Applications
D
High-Speed DSP Front-End
D
Automotive Applications
DESCRIPTION
The THS1207 is a CMOS, low-power, 12-bit, 6 MSPS
analog-to-digital converter (ADC). The speed,
resolution, bandwidth, and single-supply operation are
suited for applications in radar, imaging, high-speed
acquisition, and communications. A multistage
pipelined architecture with output error correction logic
provides for no missing codes over the full operating
temperature range. Internal control registers are used
D0
D1
D2
D3
D4
D5
BV
DD
BGND
D6
D7
D8
D9
D10/RA0
D11/RA1
CONV_CLK
SYNC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
AINP
AINM
BINP
BINM
REFIN
REFOUT
REFP
REFM
AGND
AV
DD
CS0
CS1
WR (R/W)
RD
DV
DD
DGND
ORDERING INFORMATION
PACKAGED DEVICE
TA
0擄C to 70擄C
鈥?0擄C to 85擄C
TSSOP
(DA)
THS1207CDA
THS1207IDA
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments
semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date. Products
conform to specifications per the terms of Texas Instruments standard warranty.
Production processing does not necessarily include testing of all parameters.
Copyright
錚?/div>
2002, Texas Instruments Incorporated
