6.5 碌m x 6.5 碌m Photodiode Pixel, at 6.5 碌m Pitch
2 x 2 Outputs
High Output Data Rate: 4 x 5 MHz
High Dynamic Range: 10000: 1
Antiblooming and Exposure Time Control
Very Low Lag
56 lead 0.6" DIL Package
Description
Atmel鈥檚 TH7834C is a linear sensor based on charge-coupled device (CCD) technol-
ogy. It can be used in a wide range of applications thanks to operating mode flexibility,
very high definition and high dynamic range (document scanning, digital photography,
Art, Industrial and Scientific Applications).
Pixel 1
mark
VOS1
VDR1
VS1
桅R1-2
VSS
VST
桅A1-2
VGS1-2
VS
桅3A
桅1A
桅4A
桅2A
VSS
VSS
桅2C
桅4C
桅1C
桅3C
VSS
桅P3-4
VA3-4
桅LS3-4
VSS
VDD3-4
VS3
VDR3
VOS3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
VOS2
VDR2
VS2
VDD1-2
VSS
桅LS1-2
VA1-2
桅P1-2
VSS
桅3D
桅1D
桅4D
桅2D
VSS
VSS
桅2B
桅4B
桅1B
桅3B
VSS
VGS3-4
桅A3-4
VST
VSS
桅R3-4
VS4
VDR4
VOS4
Very High-
resolution
Linear CCD
Image Sensor
(12000 Pixels)
TH7834C
TOP VIEW
Rev. 1997A鈥揑MAGE鈥?5/02
