TC04A-200TD Datasheet

  • TC04A-200TD

  • Battery Tracking TransClamp For SLIC Linecard Protection

  • 8頁

  • SEMTECH   SEMTECH

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Battery Tracking TransClamp聶
For SLIC Linecard Protection
PROTECTION PRODUCTS
Description
The battery tracking TransClamp series of transient
voltage suppressors (TVS) are designed to protect
subscriber line interface circuit (SLIC) from transient
voltages resulting from lightning strikes and AC power
line disturbances. The TC04A-200 integrates all the
components necessary to protect SLIC ICs from line to
ground for positive and negative transients.
For negative transient events, the TVS thyristor will
crowbar or 聯fire聰 when the line voltage exceeds the
gate reference voltage. The gate voltage is referenced
to the battery voltage ( -V
BAT
) plus the V
F
of the series
rectifier. The device firing voltage range is -5V to
-100V. For positive transients, the surge-rated rectifi-
ers will be forward biased, shunting the current to
ground. An external capacitor is used to aid in gate
triggering during fast rise time transients.
The device may be used to protect any SLIC including
those with integrated ring generators.
These devices are designed to meet industry standard
transient immunity requirements such as Bellcore TR-
NWT-001089, FCC Part 68, ITU K17-K20, and IEC
61000-4-5. The integrated design saves board space
and increases equipment reliability by replacing mul-
tiple discrete components.
TC04A-200
PRELIMINARY
Features
u
Transient protection for telecommunications lines to
u
u
u
u
u
u
u
Bellcore 1089 (long haul), VDE 0433, ITU K20
IEC 61000-4-5 (Lightning), and FCC Part 68
High surge current rating (100A, tp = 10/1000碌s)
Protects up to four Tip & Ring line pairs
Gate firing voltage is referenced to the system
battery voltage
Wide firing voltage range: -5V to -100V
High holding current: 200mA
Replaces multiple discrete components
Solid-state TVS process technology
Mechanical Characteristics
u
JEDEC SO-16 WB package
u
Molding compound flammability rating:
UL 94V-0
u
Marking : Part number, date code, logo
u
Packaging : Tube or Tape and Reel per EIA 481
Applications
u
u
u
u
u
u
u
Subscriber Line Interface Circuit (SLIC) Protection
Central Office Equipment
ISDN Terminal Adaptors
Cable Telephony
Small Office Home Office (SOHO) Applications
Wireless Local Loop (WLL)
Fibre In The Loop (FITL)
Circuit Diagram (Each Line)
Schematic & PIN Configuration
1
16
Line
Line
2
15
3
14
4
13
-VBat
5
12
6
11
7
10
8
9
GND
SO-16 WB Top View
Revision 9/2000
1
www.semtech.com
