TB28F200BX-B80 Datasheet

  • TB28F200BX-B80

  • 2-MBIT (128K x 16, 256K x 8) BOOT BLOCK FLASH MEMORY FAMILY

  • 48頁

  • INTEL   INTEL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

2-MBIT (128K x 16 256K x 8)
BOOT BLOCK
FLASH MEMORY FAMILY
28F200BX-T B 28F002BX-T B
Y
x8 x16 Input Output Architecture
28F200BX-T 28F200BX-B
For High Performance and High
Integration 16-bit and 32-bit CPUs
x8-only Input Output Architecture
28F002BX-T 28F002BX-B
For Space Constrained 8-bit
Applications
Upgradeable to Intel鈥檚 SmartVoltage
Products
Optimized High-Density Blocked
Architecture
One 16-KB Protected Boot Block
Two 8-KB Parameter Blocks
One 96-KB Main Block
One 128 KB Main Block
Top or Bottom Boot Locations
Extended Cycling Capability
100 000 Block Erase Cycles
Automated Word Byte Write and
Block Erase
Command User Interface
Status Registers
Erase Suspend Capability
SRAM-Compatible Write Interface
Automatic Power Savings Feature
1 mA Typical I
CC
Active Current in
Static Operation
Y
Hardware Data Protection Feature
Erase Write Lockout during Power
Transitions
Very High-Performance Read
60 80 120 ns Maximum Access Time
30 40 40 ns Maximum Output Enable
Time
Low Power Consumption
20 mA Typical Active Read Current
Reset Deep Power-Down Input
0 2
mA
I
CC
Typical
Acts as Reset for Boot Operations
Extended Temperature Operation
b
40 C to
a
85 C
Write Protection for Boot Block
Industry Standard Surface Mount
Packaging
28F200BX JEDEC ROM Compatible
44-Lead PSOP
56-Lead TSOP
28F002BX 40-Lead TSOP
12V Word Byte Write and Block Erase
V
PP
e
12V
g
5% Standard
V
PP
e
12V
g
10% Option
ETOX
TM
III Flash Technology
5V Read
Independent Software Vendor Support
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Other brands and names are the property of their respective owners
Information in this document is provided in connection with Intel products Intel assumes no liability whatsoever including infringement of any patent or
copyright for sale and use of Intel products except as provided in Intel鈥檚 Terms and Conditions of Sale for such products Intel retains the right to make
changes to these specifications at any time without notice Microcomputer Products may have minor variations to this specification known as errata
COPYRIGHT
INTEL CORPORATION 1995
November 1995
Order Number 290448-005
