T15V4M16A-70C Datasheet

  • T15V4M16A-70C

  • 256K X 16 LOW POWER CMOS STATIC RAM

  • 12頁

  • TMT

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

tm
TE
CH
Preliminary T15V4M16A
SRAM
FEATURES
鈥?/div>
Low-power consumption
- Active: 5mA (I
CC1
)
- Stand-by: 10uA (CMOS input/output)
鈥?/div>
55/70/100 ns access time
鈥?/div>
Equal access and cycle time
鈥?/div>
Single +2.7V to 3.6V Power Supply
鈥?/div>
TTL compatible , Tri-sta te output
鈥?/div>
Common I/O capability
鈥?/div>
Automatic power-down when deselected
鈥?/div>
Available in 44-PIN TSOP-II and 48-pin CSP
packages
256K X 16 LOW POWER
CMOS STATIC RAM
GENERAL DESCRIPTION
The T15V4M16A is a very Low Power
CMOS Static RAM organized as 262,144 words by
16 bits. That operates on a wide voltage range
from 2.7V to 3.6V power supply, Fabricated using
high performance CMOS technology, Inputs and
three-state outputs are TTL compatible and allow
for direct interfacing with common system bus
structures. Data retention is guaranteed at a power
supply voltage as low as 1.5V.
BLOCK DIAGRAM
PART NUMBER EXAMPLES
PART NO.
T15V4M16A-55S
T15V4M16A-70C
T15V4M16A-100C
PACKAGE CODE
S = TSOP-II
C = CSP
Vcc
Vss
A0
.
.
.
DECODER
CORE
ARRAY
A17
CE
WE
OE
LB
UB
CONTROL
CIRCUIT
DATA I/O
I/O1
.
.
.
I/O16
Taiwan Memory Technology, Inc. reserves the right
to change products or specifications without notice.
P. 1
Publication Date: SEP. 2000
Revision:0.B
