Advanced Information

SVG-2066 / SVG-2066Z

Product Description

Sirenza Microdevices鈥?SVG-2066 is an IC based 6-bit digi-

tal 31.5dB range attenuator cascaded with a linear class A

amplifier in a low-cost surface-mountable 6x6 QFN plastic

package. This product is specifically designed as a high lin-

earity variable gain amplifier for infrastructure equipment

that can be used in either the RF transmit or RF receive

path. It features both parallel or serial programmability, pro-

grammable power up states, latchable parallel control, 3V

or 5V combatible logic and robust Class 1B ESD. The SVG-

2066 features configurable pin I/O鈥檚 for optimizing the part

over application specific bands.

500MHz - 2200MHz 6-Bit Variable Gain Amp

Pb

RoHS Compliant

&

Green

Package

6mm x 6mm QFN Package

Product Features

Functional Block Diagram

Serial or

Parallel Select

S-P

VDD

2 Bit Power Up

State Programming

U1 U2

Serial Interface

DATA

CLK

LE

VCC

RFIN

RFOUT

鈥?/div>

P1dB = 25dBm @ 2140MHz

OIP3 Typical 41dBm @ 2GHz

Gain = 15dB at 850MHz

31.5dB Attenuation range in 0.5dB steps

Serial or Parallel Controlled

Optional Latched Parallel Control

Programmable Power Up States

Immune to Latch-Up

Positive Supply Voltage

3V or 5V Logic Compatible

Applications

CDMA, W-CDMA Tx and Rx

GSM, EDGE Tx and Rx

High Performance VGA applications

Unit

MHz

dBm

Min.

500

24

23.5

25

15

9.5

11

39

41

5.9

6.9

9

12

320

100

115

70

130

7.9

13.5

Typ.

Max.

2200

P0.5 P1 P2 P4 P8 P16

6-Bit Parallel Interface

Key Specifications

Symbol

f

O

P

1dB

S

21

IP3

Parameters: Test Conditions, App circuit page 4

Z

0

= 50鈩? V

CC

= 5.0V, Vdd=3V, I = 115mA, T

L

= 30潞C

Frequency of Operation

Output Power at 1dB Compression 鈥?850MHz

Output Power at 1dB Compression 鈥?2.14GHz

Small Signal Gain 鈥?850MHz @ 0dB state

Small Signal Gain 鈥?2.14GHz @ 0dB state

Third Order Intercept (Pout = 9dBm per tone) - 850MHz

Third Order Intercept (Pout = 9dBm per tone) - 2.14GHz

Noise Figure at 850 MHz @ 0 dB state

Noise Figure at 2140 MHz @ 0 dB state

Input Return Loss 850-2200 MHz ( 0dB attenuation )

Output Return Loss 850-2200MHz ( 0dB attenuation )

10%/90% Settling time

Current (Vcc = 5V,Vdd=3v)

Thermal Resistance (junction - lead)

dB

dBm

NF

IRL

ORL

Ts

Icq

R

th, j-l

dB

nS

mA

潞C/W

The information provided herein is believed to be reliable at press time. Sirenza Microdevices assumes no responsibility for inaccuracies or ommisions.

Sirenza Microdevices assumes no responsibility for the use of this information, and all such information shall be entirely at the user鈥檚 own risk. Prices and specifications are subject to change without

notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. Sirenza Microdevices does not authorize or warrant any Sirenza Microdevices product

for use in life-support devices and/or systems.

303 South Technology Court Broomfield, CO 80021

Phone: (800) SMI-MMIC

1

http://www.sirenza.com

EDS-104432 Rev 3
