ST7LITE0, ST7SUPERLITE

8-BIT MCU WITH SINGLE VOLTAGE FLASH MEMORY,

DATA EEPROM, ADC, TIMERS, SPI

Memories

鈥?1K or 1.5K bytes single voltage Flash Pro-

gram memory with read-out protection, In-Cir-

cuit and In-Application Programming (ICP and

IAP). 10K write/erase cycles guaranteed, data

retention: 20 years at 55擄C.

鈥?128 bytes RAM.

鈥?128 bytes data EEPROM with read-out pro-

tection. 300K write/erase cycles guaranteed,

data retention: 20 years at 55擄C.

Clock, Reset and Supply Management

鈥?3-level low voltage supervisor (LVD) and aux-

iliary voltage detector (AVD) for safe power-

on/off procedures

鈥?Clock sources: internal 1MHz RC 1% oscilla-

tor or external clock

鈥?PLL x4 or x8 for 4 or 8 MHz internal clock

鈥?Four Power Saving Modes: Halt, Active-Halt,

Wait and Slow

Interrupt Management

鈥?10 interrupt vectors plus TRAP and RESET

鈥?4 external interrupt lines (on 4 vectors)

I/O Ports

鈥?13 multifunctional bidirectional I/O lines

鈥?9 alternate function lines

鈥?6 high sink outputs

2 Timers

鈥?One 8-bit Lite Timer (LT) with prescaler in-

cluding: watchdog, 1 realtime base and 1 in-

put capture.

DIP16

SO16

150鈥?/div>

鈥?One 12-bit Auto-reload Timer (AT) with output

compare function and PWM

1 Communication Interface

鈥?SPI synchronous serial interface

A/D Converter

鈥?8-bit resolution for 0 to V

鈥?Fixed gain Op-amp for 11-bit resolution in 0 to

250 mV range (@ 5V V

)

鈥?5 input channels

Instruction Set

鈥?8-bit data manipulation

鈥?63 basic instructions

鈥?17 main addressing modes

鈥?8 x 8 unsigned multiply instruction

Development Tools

鈥?Full hardware/software development package

Device Summary

Features

Program memory - bytes

RAM (stack) - bytes

Data EEPROM - bytes

Peripherals

Operating Supply

CPU Frequency

Operating Temperature

Packages

ST7SUPERLITE

ST7LITES2

ST7LITES5

ST7LITE02

ST7LITE0

ST7LITE05

ST7LITE09

1.5K

128 (64)

LT Timer w/ Wdg,

AT Timer w/ 1 PWM, AT Timer w/ 1 PWM, AT Timer w/ 1 PWM,

SPI

SPI, 8-bit ADC

SPI

2.4V to 5.5V

1MHz RC 1% + PLLx4/8MHz

-40擄C to +85擄C

SO16 150鈥? DIP16

1.5K

128 (64)

128

LT Timer w/ Wdg,

AT Timer w/ 1 PWM, SPI,

8-bit ADC w/ Op-Amp

Rev. 2.4

August 2003

1/122

其它有關文件
ST7LITE05Y0 View All Specifications
標準包裝
50
類別
集成電路 (IC)
家庭
嵌入式 - 微控制器，
系列
ST7
核心處理器
ST7
芯體尺寸
8-位
速度
16MHz
連通性
SPI
外圍設備
LVD，POR，PWM，WDT
輸入/輸出數
13
程序存儲器容量
1.5KB（1.5K x 8）
程序存儲器類型
閃存
EEPROM 大小
-
RAM 容量
128 x 8
電壓 - 電源 (Vcc/Vdd)
2.4 V ~ 5.5 V
數據轉換器
A/D 5x8b
振蕩器型
內部
工作溫度
-40°C ~ 85°C
封裝/外殼
16-SOIC（0.154"，3.90mm 寬）
包裝
管件
配用
497-5858-ND - EVAL BOARD PLAYBACK ST7FLITE497-5080-ND - EVAL BOARD AC/AC CHOPPER DRIVER497-5049-ND - KIT STARTER RAISONANCE ST7FLITE
其它名稱
497-9030-5ST7FLITE05Y0M6-ND
