ST6200L/01L/03L

LOW VOLTAGE 8-BIT ROM MCUs WITH A/D CONVERTER,

TWO TIMERS & SAFE RESET

s

s

s

s

s

s

s

Memories

鈥?1K or 2K bytes Program memory with read-

out protection

鈥?64 bytes RAM

Clock, Reset and Supply Management

鈥?Enhanced reset system

鈥?Clock sources: crystal/ceramic resonator or

RC network, external clock

鈥?2 Power Saving Modes: Wait and Stop

Interrupt Management

鈥?4 interrupt vectors plus NMI and RESET

鈥?9 external interrupt lines (on 2 vectors)

9 I/O Ports

鈥?9 multifunctional bidirectional I/O lines

鈥?4 alternate function lines

鈥?3 high sink outputs (12mA)

2 Timers

鈥?Configurable watchdog timer

鈥?8-bit timer/counter with a 7-bit prescaler

Analog Peripheral

鈥?8-bit ADC with 4 input channels (except on

ST6203L)

Instruction Set

鈥?8-bit data manipulation

鈥?40 basic instructions

鈥?9 addressing modes

鈥?Bit manipulation

PDIP16

SO16

SSOP16

(See

Section 1.3

for Ordering Information)

s

Development Tools

鈥?Full hardware/software development package

Device Summary

Features

Program memory - bytes

RAM - bytes

Operating Supply

Analog Inputs

Clock Frequency

Operating Temperature

Packages

4

4MHz Max

0擄C to +70擄C

PDIP16 / SO16 / SSOP16

ST6200L

1K

ST6201L

2K

64

2.4V to 3.9V

-

ST6203L

1K

Rev. 1.1

July 2001

1/10

1
