ST3232

3 TO 5.5V, LOW POWER, UP TO 400KBPS,

RS-232 DRIVERS AND RECEIVERS

s

s

s

s

s

300碌A(chǔ) SUPPLY CURRENT

300Kbps MINIMUM GUARENTEED DATA

RATE

6V/碌s MINIMUM GUARANTEED SLEW RATE

MEET EIA/TIA-232 SPECIFICATIONS DOWN

TO 3V

AVAILABLE IN DIP-16, SO-16, SO-16 LARGE

AND TSSOP16

DIP

SOP

DESCRIPTION

The ST3232 is a 3V powered EIA/TIA-232 and

V.28/V.24 communication interface with low

power requirements, high data-rate capabilities.

ST3232 has a proprietary low dropout transmitter

output stage providing true RS-232 performance

from 3 to 5.5V supplies. The device requires only

four small 0.1碌F standard external capacitors for

operations from 3V supply.

The ST3232 has two receivers and two drivers.

The device is guaranteed to run at data rates of

250Kbps while maintaining RS-232 output levels.

Typical applications are Notebook, Subnotebook

and Palmtop Computers, Battery Powered

Equipment, Hand-Held Equipment, Peripherals

and Printers.

ORDERING CODES

Type

ST3232CN

ST3232BN

ST3232CD

ST3232BD

ST3232CDR

ST3232BDR

ST3232CW

ST3232BW

ST3232CWR

ST3232BWR

ST3232CTR

ST3232BTR

Temperature

Range

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

Package

DIP-16

DIP-16

SO-16 (Tube)

SO-16 (Tube)

SO-16 (Tape & Reel)

SO-16 (Tape & Reel)

SO-16 Large (Tube)

SO-16 Large (Tube)

SO-16 Large (Tape & Reel)

SO-16 Large (Tape & Reel)

TSSOP16 (Tape & Reel)

TSSOP16 (Tape & Reel)

SOP Large

TSSOP

Comments

25parts per tube / 40tube per box

25parts per tube / 40tube per box

50parts per tube / 20tube per box

50parts per tube / 20tube per box

2500 parts per reel

2500 parts per reel

49parts per tube / 25tube per box

49parts per tube / 25tube per box

1000 parts per reel

1000 parts per reel

2500 parts per reel

2500 parts per reel

May 2002

1/11
