D A T A S H E E T
Lighting
Imaging
Telecom
Fiber-Optic Receiver Modules
SR MiniDIL APD Series
SRAA 155, 622, 1.2
Fiber-Optic Receiver Modules
Description
The SRAA series incorporates a high-speed
InGaAs photodiode with a GaAs
transimpedance amplifier in an 8 pin
miniDIL package for digital communication
applications. This series of fiber-optic
receiver modules conforms to Synchronous
Optical Network (SONET) requirements for
OC-3, 12 (155, 622 Mbps) and OC-24 (1.2
Gbps) receivers used in long-range,
intermediate-range and short-range
applications. The transimpedance amplifier
with automatic gain control provides a
cost-effective upgrade path from PIN
photodiodes for applications such as ATM-
SDH transmission equipment, Fiber
Channel, FDDI, 100 Mbps Ethernet, or
custom fiber optics. Receiver modules are
available in industry-standard fibered
packages with either multi-mode or
single-mode pigtail.
Committed to supplying the highest quality
products, PerkinElmer Optoelectronics is
certified to meet ISO 9001. The SRAA
series is designed to satisfy Telcordia
quality specification GR-468-CORE.
All devices undergo periodic process
qualification programs to assure high
reliability.
Applications
鈥?/div>
Long haul transmission equipment
鈥?/div>
Digital video
鈥?/div>
Fiber channel test equipment
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
InGaAs APD detector
GaAs TIA
155, 622 Mbps and 1.2 Gbps
Automatic Gain Control
Fibered and connectorized modules
Internally beveled fiber for low return loss
High reliability
.
www.perkinelmer.com/opto
