Units 15-16, Redfields Industrial Park, Redfields Lane,
Church Crookham, Hants, GU13 0RD, England.
Tel:
+44 (0)1252-851510 Email: sales@videoswitch.co.uk
Fax: +44 (0)1252-851296 Web: www.videoswitch.co.uk
DATASHEET
2
These easy-to-use C.C.T.V Multiplexers provide excellent performance and picture quality combined with a
.
comprehensive set of features. The latest technology has been used in these new generation products to
deliver maximum reliability and value for money.
Mini-Simplex
Simplex Operation
鈥淢ini鈥?Case
Order Codes:
VM-801M (mono)
VM-801C (colour)
Mini-Duplex
Plus
Duplex Operation
Dual Quad Outputs
鈥淢ini鈥?Case
Order Codes:
VM-802M (mono)
VM-802C (colour)
Duplex
Plus
Duplex Operation
Dual Quad Outputs
Loop-Through
S-Video Record & Play
19鈥?1U Case
Order Codes:
VM-803M (mono)
VM-803C (colour)
Telemetry Duplex
Plus
Duplex Operation
Dual Quad Outputs
Joystick for Dome and Receiver Control
Coax and Twisted Pair Telemetry
Loop-Through
S-Video Record & Play
19鈥?1U Case
Order Codes:
VM-804M (mono)
VM-804C (colour)
All These Multiplexers Feature...
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Easy Set Up
Very High Image Quality
5 Year Warranty
8 Camera Inputs
2 Monitor Outputs (one may be configured as Public)
Both Monitors can display all Screen Modes and Text
Accept Colour, Monochrome and Switching Cameras
50 Fields per Second Maximum Multiplexing Rate (PAL)
Time-Lapse Multiplexing up to 960 Hour Mode
720 x 546 Image Resolution (PAL)
Analogue or Digital Live Full Screen Display
Quad Displays
8-Way Multi-Screen (text in centre)
Picture-in-Picture
Freeze Frame
x4 Digital Zoom
Anti-Flicker Mode for Multi-Screen Images
Activity Detection, 14 x 10 zones with sensitivity control
Alarm Inputs (individually set to normally open/closed)
Video Loss detection
Covert (Hidden) on any Cameras
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Automatic VCR Synchronisation
Auto Sequencing
Random Sequencing
Remote Control via RS232, RS485 and RS422 using
Videoswitch VXP-4 Protocol
Time and Date, Battery Backup
16 Character Camera Identification
Daily Timers for Alarms/Activity/Time-Lapse Modes
Alarm Relay Contacts
Selectable Termination on each Camera
Adjustable Gain (Brightness) on each Camera
PAL and NTSC
Password Protected Menus
Different Password Access for User, Manager & Installer
Powered via External 12Vdc Linear Supply
Designed, Manufactured and Supported in the UK
Duplex
Plus
is the Videoswitch feature which enables
you to display a different multi-screen image on each
monitor.
3
