Geode鈩?SC2200 Thin Client On a Chip
August 2002
Revision 3.0
Geode鈩?SC2200
Thin Client On a Chip
General Description
The Geode鈩?SC2200 Thin Client On a Chip device is a
member of the National Semiconductor
廬
IA (Information
Appliance) on a Chip family of fully integrated x86 system
chips. The Geode SC2200 includes:
鈥?/div>
The Geode GX1 processor module combines advanced
CPU performance with Intel MMX support, fully acceler-
ated 2D graphics, a 64-bit synchronous DRAM
(SDRAM) interface, a PCI bus controller, and a display
controller.
鈥?/div>
A low-power CRT and TFT Video Processor module with
a Video Input Port (VIP), and a hardware video acceler-
ator for scaling, filtering, and color space conversion.
鈥?/div>
The Core Logic module includes: PC/AT functionality, a
USB interface, an IDE interface, a PCI bus interface, an
LPC bus interface, Advanced Configuration Power Inter-
face (ACPI) version 1.0 compliant power management,
and an audio codec interface.
鈥?/div>
The SuperI/O module has: three serial ports (UART1,
UART2, and UART3 with fast infrared), a parallel port,
two ACCESS.bus (ACB) interfaces, and a real-time
clock (RTC).
The block diagram shows the relationships between the
modules.
These features, combined with the device鈥檚 small form fac-
tor and low power consumption, make it ideal as the core
for a thin client application.
Block Diagram
GX1
Memory Controller
2D Graphics
Accelerator
PCI Bus
Controller
Display
Controller
CRT I/F
Video
Scaling
Config.
Block
Video Input Port (VIP)
Host Interface
Fast-PCI Bus
Clock & Reset Logic
Fast X-Bus
Video
Mixer
TFT I/F
Video Processor
CPU
Core
IDE I/F
Bridge
USB
PCI/Sub-ISA
Bus I/F
GPIO
Audio Codec I/F
LPC I/F
X-Bus
PCI Bus
Core Logic
PIT
PIC
DMAC
Pwr Mgmnt
Configuration
ISA Bus I/F
RTC
Parallel
Port
ACB1
I/F
SuperI/O
ACB2
I/F
UART1
UART2
ISA Bus
I/F
UART3
& IR
National Semiconductor and Virtual System Architecture are registered trademarks of National Semiconductor Corporation.
Geode and VSA are trademarks of National Semiconductor Corporation.
For a complete listing of National Semiconductor trademarks, please visit www.national.com/trademarks.
漏 2002 National Semiconductor Corporation
www.national.com
