SBYV28-50 thru SBYV28-200
Vishay Semiconductors
formerly General Semiconductor
Soft Recovery
Ultrafast Plastic Rectifier
DO-201AD
Reverse Voltage
50 to 200V
Forward Current
3.5A
Features
1.0 (25.4)
Min.
0.210 (5.3)
0.190 (4.8)
Dia.
0.375 (9.5)
0.285 (7.2)
鈥?Plastic package has Underwriters Laboratories
Flammability Classification 94V-0
鈥?Ideally suited for use in very high frequency switching
power supplies, inverters and as free wheeling diodes
鈥?Ultrafast recovery time for high efficiency
鈥?Glass passivated junction
鈥?High temperature soldering guaranteed:
250擄C/10 seconds, 0.375" (9.5mm) lead length,
5 lbs. (2.3kg) tension
Mechanical Data
1.0 (25.4)
Min.
0.052 (1.32)
0.048 (1.22)
Dia.
Dimensions in inches and (millimeters)
Case:
JEDEC DO-201AD molded plastic body over
passivated chip
Terminals:
Plated axial leads, solderable per
MIL-STD-750, Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:
0.045 oz., 1.2 g
Maximum Ratings & Thermal Characteristics
Ratings at 25擄C ambient temperature unless otherwise specified.
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Minimum reverse breakdown voltage at 100碌A(chǔ)
Maximum average forward rectified current
0.375鈥?(9.5mm) lead lengths at T
L
= 85擄C
Peak forward surge current
8.3 ms single half sine-wave superimposed
on rated load at T
J
= 150擄C
Typical thermal resistance
(1)
Symbols
SBYV28-50 SBYV28-100 SBYV28-150 SBYV28-200
Units
V
RRM
V
RMS
V
DC
V
(BR)
I
F(AV)
50
35
50
55
100
70
100
110
3.5
150
105
150
165
200
140
200
220
V
V
V
V
A
I
FSM
R
螛JA
T
J
, T
STG
90
25
-55 to +150
A
擄C/W
擄C
Operating and storage temperature range
Electrical Characteristics
Parameter
Maximum instantaneous forward voltage
at 3.5A
(2)
Maximum DC reverse current
at rated DC blocking voltage
Maximum reverse recovery time
at I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A
Typical junction capacitance at 4.0V, 1MHz
Ratings at 25擄C ambient temperature unless otherwise specified.
Symbols
SBYV28-50 SBYV28-100 SBYV28-150 SBYV28-200
Units
T
J
=25擄C
T
J
=150擄C
T
A
=25擄C
T
A
=100擄C
T
J
=25擄C
V
F
I
R
t
rr
C
J
1.1
0.89
5.0
300
20
20
V
碌A(chǔ)
ns
pF
Notes:
(1) Lead length = 3/8鈥?on P.C. Board with 1.5鈥?x 1.5鈥?copper surface
(2) Pulse test: t
p
= 300碌s, duty cycle
鈮?/div>
2%
Document Number 88737
11-Feb-02
