NON-ISOLATED DC/DC CONVERTERS
5V Input / 0.9V 鈥?3.3V Output / 8A
S7AH-08B / V7AH-08B Series
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Nonisolated
Compact, low profile surface mount package
Fixed frequency
High efficiency means less power dissipation
Excellent thermal performance
Optimized for cost
Remote on/off
Undervoltage lockout (UVLO)
Over current and short circuit protection
POWER PRODUCTS
BP03x7AH-08B
Description
The Bel S7AH-08B and V7AH-08B modules are a series of non-isolated, step down DC/DC power converters that operate
from a nominal 5V source. These converters are available in a range of output voltages from 0.9V to 3.3V. They are packaged
in a compact, overmolded package rated at 8A. Optional lead forming provides a vertical mount product for minimal footprint
or a surface mount option for a very low profile. Standard features include remote on/off, over current and short circuit
protection, output voltage adjust and industrial temperature range (-40擄 to +85擄 C). The output is closely regulated and the
efficiency is typically 92% at full load. These products may be used almost anywhere low voltage silicon is employed and a 5V
source is available. Typical applications include file servers, routers, line cards and other computing and communications
equipment.
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Distributed power architectures
Data networking equipment
Telecommunications
Computers and peripherals
Part Number Selection
Output
Voltage
3.3V
2.5V
1.8V
1.5V
1.2V
1.0V
0.9V
0.9V - 3.3V
Input
Voltage
5V
5V
5V
5V
5V
5V
5V
5V
Max. Output
Current
8A
8A
8A
8A
8A
8A
8A
8A
Max. Output
Power
26.4W
20W
14.4W
12W
9.6W
8W
7.2W
26.4W
Typical
Efficiency
92%
90%
86%
84%
82%
80%
79%
92%
Part Number
Surface Mount
S7AH-08B330
S7AH-08B250
S7AH-08B180
S7AH-08B150
S7AH-08B120
S7AH-08B100
S7AH-08B090
S7AH-08B1A0
Part Number
Vertical Mount
V7AH-08B330
V7AH-08B250
V7AH-08B180
V7AH-08B150
V7AH-08B120
V7AH-08B100
V7AH-08B090
V7AH-08B1A0
漏2004 Bel Fuse Inc.
Specifications subject to change without notice. 01.04
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
