2:1 Wide Range Voltage Input
1kVDC, 2kVD & 3kVDC Isolation
UL94V-0 Package Material
Continuous Short Circuit Protection
with Current Foldback
Low Noise
No External Capacitor needed
Efficiency to 83%
ECONOLINE
DC/DC-Converter
RSO
Series
Capacitive
Load max.
碌F
470
470
220
100
47
470
470
220
100
47
470
470
220
100
47
470
470
220
100
47
鹵220
鹵220
鹵100
鹵47
鹵22
鹵220
鹵220
鹵100
鹵47
鹵22
鹵220
鹵220
鹵100
鹵47
鹵22
鹵220
鹵220
鹵100
鹵47
鹵22
www.recom-international.com
Selection Guide
5V, 12V, 24V and 48V Input Types
Part Number
SIP8
RSO-053.3S (H2/H3)
RSO-0505S (H2/H3)
RSO-0509S (H2/H3)
RSO-0512S (H2/H3)
RSO-0515S (H2/H3)
RSO-123.3S (H2/H3)
RSO-1205S (H2/H3)
RSO-1209S (H2/H3)
RSO-1212S (H2/H3)
RSO-1215S (H2/H3)
RSO-243.3S (H2/H3)
RSO-2405S (H2/H3)
RSO-2409S (H2/H3)
RSO-2412S (H2/H3)
RSO-2415S (H2/H3)
RSO-483.3S (H2/H3)
RSO-4805S (H2/H3)
RSO-4809S (H2/H3)
RSO-4812S (H2/H3)
RSO-4815S (H2/H3)
RSO-053.3D (H2/H3)
RSO-0505D (H2/H3)
RSO-0509D (H2/H3)
RSO-0512D (H2/H3)
RSO-0515D (H2/H3)
RSO-123.3D (H2/H3)
RSO-1205D (H2/H3)
RSO-1209D (H2/H3)
RSO-1212D (H2/H3)
RSO-1215D (H2/H3)
RSO-243.3D (H2/H3)
RSO-2405D (H2/H3)
RSO-2409D (H2/H3)
RSO-2412D (H2/H3)
RSO-2415D (H2/H3)
RSO-483.3D (H2/H3)
RSO-4805D (H2/H3)
RSO-4809D (H2/H3)
RSO-4812D (H2/H3)
RSO-4815D (H2/H3)
50
Input
Voltage Range
(VDC)
4.5 - 9
4.5 - 9
4.5 - 9
4.5 - 9
4.5 - 9
9 - 18
9 - 18
9 - 18
9 - 18
9 - 18
18 - 36
18 - 36
18 - 36
18 - 36
18 - 36
36 - 72
36 - 72
36 - 72
36 - 72
36 - 72
4.5 - 9
4.5 - 9
4.5 - 9
4.5 - 9
4.5 - 9
9 - 18
9 - 18
9 - 18
9 - 18
9 - 18
18 - 36
18 - 36
18 - 36
18 - 36
18 - 36
36 - 72
36 - 72
36 - 72
36 - 72
36 - 72
Rated Output
Voltageat
(VDC)
3.3
5
9
12
15
3.3
5
9
12
15
3.3
5
9
12
15
3.3
5
9
12
15
鹵3.3
鹵5
鹵9
鹵12
鹵15
鹵3.3
鹵5
鹵9
鹵12
鹵15
鹵3.3
鹵5
鹵9
鹵12
鹵15
鹵3.3
鹵5
鹵9
鹵12
鹵15
Output Current
Full Load
(mA)
300
200
111
83
67
300
200
111
83
67
300
200
111
83
67
300
200
111
83
67
鹵150
鹵100
鹵56
鹵42
鹵34
鹵150
鹵100
鹵56
鹵42
鹵34
鹵150
鹵100
鹵56
鹵42
鹵34
鹵150
鹵100
鹵56
鹵42
鹵34
Efficiency
typ.
(%)
68
73
74
75
75
69
75
78
80
80
70
78
81
83
83
70
75
78
80
80
71
74
75
76
76
76
79
80
81
81
74
77
78
80
80
70
75
78
80
80
January-2007
1 Watt
SIP8 Isolated
Single
&
Dual
Output
EN-60950-1 Certified
EN-60601-1 Certified
(Suffix H2/H3)
1
2
3
