Solid State Relays
PCB, 1-Phase ZS/IO
Type RP 130 ...-.-., RP 132 ...-.-.
鈥?AC Solid State Relay for PCB mounting
鈥?Zero or instant-on switching
鈥?Rated operational current: 2 and 4 AAC
鈥?Non-repetitive voltage: Up to 850 Vp
鈥?Rated operational voltage range: Up to 400 VACrms
鈥?Input range: 3 to 32 VDC
鈥?Insulation: OPTO (input-output) 4000 VACrms
Product Description
The zero switching relay for
PCB mounting is used for a
wide range of applications
with either resistive or induc-
tive loads.
The zero switching relay swit-
ches on when the AC sine
curve just crosses the zero
value, and the relay switches
off when the current crosses
zero.
The instant-on switching
relay switches on immediate-
ly when the control voltage is
applied. The relay switches
off when the current crosses
the zero value.
Ordering Key
Solid State Relay (PCB)
Switching mode
Rated operational voltage
Rated operational current
Control voltage
RP 130 240-4-0
Type Selection
Switching mode
130: Zero switching
132: Instant-on switching
Rated operational voltage
240: 230 VACrms
440: 400 VACrms
Rated operational current
2: 2 AACrms
4: 4 AACrms
Control voltage
0: 3 to 32 VDC
Selection Guide
Rated operational voltage
Control voltage
Rated operational current
2 AACrms
RP 130 240-2-0*
RP 132 240-2-0**
RP 130 440-2-0*
RP 132 440-2-0**
4 AACrms
RP 130 240-4-0*
RP 132 240-4-0**
RP 130 440-4-0*
RP 132 440-4-0**
230 VACrms
400 VACrms
* Zero switching
** Instant-on switching
3 to 32 VDC
3 to 32 VDC
General Specifications
RP 13. 240-.-0
Operational voltage range
Non-rep. peak voltage
Zero voltage turn-on
Operational frequency range
Power factor
Approvals
CE-marking
24 to 280 VACrms
鈮?/div>
650 V
p
鈮?/div>
20 V
45 to 65 Hz
鈮?/div>
0.5 @ 230 VACrms
UL, CSA, VDE
Yes
RP 13. 440-.-0
48 to 480 VACrms
鈮?/div>
850 V
p
鈮?/div>
40 V
45 to 65 Hz
鈮?/div>
0.5 @ 400 VACrms
UL, CSA, VDE
Yes
Specifications are subject to change without notice
(30.06.1999)
1
