Solid State Relays
PCB, 1-Phase ZS
Types RP 130 ...-.-05, RP 130 ...-.-12, RP 130 ...-.-24
鈥?AC Solid State Relay for PCB mounting
鈥?Zero switching
鈥?Rated operational current: 3 or 5 AACrms
鈥?Non-repetitive voltage: Up to 850 V
p
鈥?Rated operational voltage: 240 V or 440 VACrms
鈥?5 VDC logic compatible input
鈥?12 and 24 VDC inputs for interfacing PLCs and
other controls
鈥?Insulation: OPTO (input-output) 4000 VACrms
Product Description
The RP Solid State Relays
from Carlo Gavazzi feature a
very reliable design due to use
of optotechnology together
with high performance power
semiconductors.
Either 3 or 5 A relays are avail-
able for AC mains up to 400
VACrms.
The zero switching version
will work for resistive and in-
ductive loads.
With snubberless triacs as
output devices, dV/dt limiting
RC-networks are no longer
required when switching in-
ductive loads.
Ordering Key
Solid State Relay (PCB)
Mounting type
Switching mode
Rated operational voltage
Rated operational current
Control voltage
RP 130 240-5-12
Type Selection
Switching mode
130: Zero switching
Rated operational voltage
240: 230 VACrms
440: 400 VACrms
Rated operational current
3: 3 AACrms
5: 5 AACrms
Control voltage
05:
12:
24:
5 VDC
12 VDC
24 VDC
Selection Guide
Rated operational
voltage
Control voltage
5 VDC
12 VDC
230 VACrms
24 VDC
5 VDC
12 VDC
400 VACrms
24 VDC
Rated operational current
3 AACrms
RP 130 240-3-05
RP 130 240-3-12
RP 130 240-3-24
RP 130 440-3-05
RP 130 440-3-12
RP 130 440-3-24
5 AACrms
RP 130 240-5-05
RP 130 240-5-12
RP 130 240-5-24
RP 130 440-5-05
RP 130 440-5-12
RP 130 440-5-24
