2.2W DIP Package
1kVDC Isolation
Regulated Output
UL94V-0 Package Material
Continuous Short Circuit Protection
Internal SMD design
100% Burned In
Efficiency to 75%
ECONOLINE
DC/DC-Converter
REC2.2-
S_DR/H1
Series
Output
Current
(mA)
600
440
244
183
146
Selection Guide
Part
Number
DIP24
REC2.2-xx3.3SR/H1
REC2.2-xx05SR/H1
REC2.2-xx09SR/H1
REC2.2-xx12SR/H1
REC2.2-xx15SR/H1
REC2.2-xx05DR/H1
REC2.2-xx09DR/H1
REC2.2-xx12DR/H1
REC2.2-xx15DR/H1
xx = Input Voltage
Input
Voltage
(VDC)
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
5, 12, 24, 48
Output
Voltage
(VDC)
3.3
5
9
12
15
鹵5
鹵9
鹵12
鹵15
2.2 Watt
DIP24
Single
&
Dual Output
鹵220
鹵122
鹵92
鹵73
Specifications
(Core Operating Area)
Input Voltage Range
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation (10% to 100% full load )
Output Ripple and Noise (at 20MHz BW)
Operating Frequency
Efficiency at Full Load
No Load Power Consumption
Isolation Voltage
Rated Working Voltage
Isolation Capacitance
Isolation Resistance
Short Circuit Protection
Operating Temperature Range (free air convection)
Storage Temperature Range
Relative Humidity
Thermal Impedance
Package Weight
MTBF (+25擄C)
(+80擄C)
MSL Level 1
Natural convection
(tested for 1 second)
(long term isolation)
鹵15%
鹵3% typ.
鹵0.5% max
鹵1% max.
100mVp-p max.
75kHz min.
65% min.
200mW max.
1.000VDC min.
see Application Notes
30pF typ.
Output Power (%)
100
80
60
40
30
20
0
Derating-Graph
(Ambient Temperature)
1 G鈩?min.
Continuous
-40擄C to +80擄C (see Graph)
-50擄C to +125擄C
95% RH
20擄C/W for metal case
12 g
1000 x 10
3
hours
150 x 10
3
hours
Safe Operating Area
80
Operating Temperature 擄C
-40
0
50
100
150
}
using MIL-HDBK 217F
Detailed Information see
Application Notes chapter "MTBF"
using MIL-HDBK 217F
www.recom-international.com
April-2005
83
