LED-indication of loop current
Product Description
The analog switching relay
works in accordance with the
phase control principle, i.e.
the output switching point in
the AC sine wave depends on
the control current. 4 to 20
mA corresponds to no switch-
ing and to full sine wave (near
linear). The relay switches off
every time the current crosses
zero, and switches ON in ac-
cordance with the applied
control current.
Ordering Key
RE 48 50 AA 12
Solid State Relay
Switching mode
Rated operational voltage
Rated operational current
4 to 20 mA control current
Non-rep. off-state peak voltage
Type Selection
Switching mode
E: Analog switching
Rated operational
voltage
24: 115 VACrms
230 VACrms
48: 400 VACrms
480 VACrms
60: 600 VACrms
Rated operational
current
10: 10 AACrms
25: 25 AACrms
50: 50 AACrms
Control current
AA: 4 to 20 mA
Non-rep. voltage
06: 650 V
p
12: 1200 V
p
16: 1600 V
p
Selection Guide
Rated operational Non-rep. voltage
voltage
115 VACrms
230 VACrms
400 VACrms
480 VACrms
600 VACrms
650 V
p
650 V
p
1200 V
p
1200 V
p
1600 V
p
Control current
Rated operational current
10 AACrms
25 AACrms
RE 2410 AA 06
RE 2410 AA 06
RE 4810 AA 12
RE 4810 AA 12
-
RE 2425 AA 06
RE 2425 AA 06
RE 4825 AA 12
RE 4825 AA 12
-
50 AACrms
RE 2450 AA 06
RE 2450 AA 06
RE 4850 AA 12
RE 4850 AA 12
RE 6050 AA 16
4 to 20 mA
4 to 20 mA
4 to 20 mA
4 to 20 mA
4 to 20 mA
General Specifications
RE 24.. AA 06
Operational voltage range
Non-rep. peak voltage
Operational frequency range
Power factor
Approvals
CE-marking
90 to 280 VACrms
鈮?/div>
600 V
p
45 to 65 Hz
0.5
UL, CSA
Yes
RE 48.. AA 12
265 to 530 VACrms
鈮?/div>
1200 V
p
45 to 65 Hz
0.5
UL, CSA
Yes
RE 6050 AA 16
330 to 660 VACrms
鈮?/div>
1600 V
p
45 to 65 Hz
0.5
UL, CSA
Yes
Specifications are subject to change without notice (30.06.1999)
