www.fairchildsemi.com

RC4194

Dual Tracking Voltage Regulators

Features

鈥?Simultaneously adjustable outputs with one resistor

鹵42V

鈥?Load current 鈥?/div>

鹵200

mA with 0.04% load regulation

鈥?Internal thermal shutdown at T

= +175擄C

鈥?External balance for

鹵V

OUT

unbalancing

鈥?3W power dissipations

Description

The RC/RM4194 are dual polarity tracking regulators

designed to provide balanced or unbalanced positive and

negative output voltages at currents to 200 mA.

A single external resistor adjustment can be used to change

both outputs between the limits of

鹵50

mV and

鹵42V.

These devices are designed for local 鈥渙n-card鈥?regulation,

eliminating distribution problems associated with single-

point regulation. To simplify application the regulators

require a minimum number of external parts.

The device is available in three package types to accommo-

date various power requirements. The K (TO-66) power

package can dissipate up to 3W at T

= +25擄C. The D

14-pin dual in-line will dissipate up to 1W and the N

14-pin dual in-line will dissipate up to 625 mW.

Block Diagram

4194

OUT

20K

GND

Comp+

100碌A(chǔ)

Current

Source

SET

Bal

20K

Comp鈥?/div>

Thermal

Shutdown

鈥揤

OUT

鈥揤

65-4194-01

Rev. 1.0.0
