Agilent HFBR/HFCT-5208M 1 x 9
Fiber Optic Transceivers for 622 Mb/s
ATM/SONET/SDH Applications
Data Sheet
Features
鈥?Performance
HFBR-5208M:
Links of 500 m with 62.5/125 碌m
multimode fiber (MMF) from
155-622 Mb/s
HFCT-5208M:
Links of 15 km with 9/125 碌m
single-mode fiber (SMF)
鈥?Compliant with ATM forum
622.08 Mb/s physical layer
specification (AF-PHY-0046.000)
鈥?Compliant with ANSI broadband
ISDN - physical layer
specification T1.646-1995 and
T1.646a-1997
鈥?HFBR-5208M is compliant with
ANSI network to customer
installation interfaces -
synchronous optical NETwork
(SONET) physical media
dependent specification:
multimode fiber T1.416.01-1998
鈥?HFCT-5208M is compliant to the
intermediate SONET OC12/SDH
STM(S4.1) specifications
鈥?Industry-standard multi-sourced
1 x 9 mezzanine package style
鈥?Single +5 V power supply
operation and PECL logic
interfaces
鈥?Wave solder and aqueous wash
process compatible
鈥?Unconditionally eye safe laser IEC
825/CDRH Class 1 compliant
Description
General
The HFBR-5208M (multimode
transceiver) and HFCT-5208M
(single-mode transceiver) from
Agilent allow the system designer
to implement a range of solutions
for ATM/SONET STS-12/SDH
STM-4 applications.
The overall Agilent transceiver
consists of three sections: the
transmitter and receiver optical
subassemblies, an electrical
subassembly and the mezzanine
package housing which
incorporates a duplex SC
connector receptacle.
Transmitter Section
The transmitter section of the
HFBR-5208M consists of a 1300 nm
LED in an optical subassembly
(OSA) which mates to the multi-
mode fiber cable. The HFCT-5208M
incorporates a 1300 nm Fabry
Perot (FP) laser in the optical
subassembly. In addition, this
package has been designed to be
compliant with IEC 825 eye-safety
requirements under any single
fault condition. The OSA鈥檚 are
driven by a custom, silicon bipolar
IC which converts differential
PECL logic signals (ECL
referenced to a +5 V supply) into
an analog LED/laser drive current.
Applications
HFBR-5208M:
鈥?General purpose low-cost MMF
links at 155 to 650 Mb/s
鈥?ATM 622 Mb/s MMF links from
switch-to-switch or switch-to-
server in the end-user premise
鈥?Private MMF interconnections at
622 Mb/s SONET STS-12/SDH
STM-4 rate
HFCT-5208M:
鈥?ATM 622 Mb/s SMF links from
switch-to-switch or switch-to-
server in the end-user premise
鈥?Private SMF interconnections at
622 Mb/s SONET STS-12/SDH
STM-4 rate
622 Mb/s Product Family
HFCT-5218M:
鈥?1300 nm laser-based transceiver
in 1 x 9 package for links of 40 km
with single-mode fiber cables
