Princeton Technology Corp.
REMOTE CONTROL ENCODER
Tel: 886-2-29162151
Fax: 886-2-29174598
URL:
http://www.princeton.com.tw
PT2260
Description
PT2260 is a remote control encoder paired with either PT2270 or PT 2272
utilizing CMOS Technology. It encodes data and address pins into a serial
coded waveform suitable for RF modulation. PT2260 has a maximum of
10 bits tri-state address pins providing up to 59,049 (or 3
10
) address codes;
thereby, drastically reducing any code collision and unauthorized code
scanning possibilities.
PT2260 is one of the first generation of Encoder/Decoder ICs that utilizes
the unique PTC Technology. When paired with PT2270, this
encoder/decoder (PT2260 / PT2270) pair can operate at very wide
temperature range (see Features). Thus, this very important feature
enables your Encoder/Decoder to operate under the worst environmental
condition.
Features
!
!
!
!
!
!
!
!
!
High Performance CMOS Technology
Low Power Consumption
Very High Noise Immunity
Wide Operating Temperature Range: -30
o
C ~ 70
o
C
8 or 10 Tri-State Code Address Pins
2 or 4 Data Pins
Wider Range of Operating Voltage: 1.8 ~ 10.0 Volts
Single Resistor Oscillator
Least External Components
Applications
!
!
!
!
Home/Car Security System
Garage Door Controller
Remote Fan Controller
Remote Control Toys
Page
1
Revised Oct. 1996
PT2260 v 1.1
