RUN: CPU on, peripherals on
IDLE: CPU off, peripherals on
SLEEP: CPU off, peripherals off
IDLE mode currents down to 5.8
碌A(chǔ)
typical
SLEEP current down to 0.1
碌A(chǔ)
typical
Timer1 oscillator: 1.1
碌A(chǔ)
typical, 32 kHz, 2V
Watchdog Timer: 2.1
碌A(chǔ)
typical
Two-Speed Oscillator Start-up
Flexible Oscillator Structure:
鈥?Four Crystal modes
- LP, XT, HS: up to 25 MHz
- HSPLL: 4-10 MHz (16-40 MHz internal)
鈥?Two External RC modes, up to 4 MHz
鈥?Two External Clock modes, up to 40 MHz
鈥?Internal oscillator block:
- 8 user selectable frequencies: 31 kHz, 125 kHz,
250 kHz, 500 kHz, 1 MHz, 2 MHz, 4 MHz, 8 MHz
- Two modes select one or two I/O pins
- OSCTUNE - Allows user to shift frequency
鈥?Secondary oscillator using Timer1 @ 32 kHz
鈥?Fail-Safe Clock Monitor
- Allows for safe shutdown if peripheral clock stops
ECAN bus Module Features:
鈥?Implements full CAN model
鈥?Conforms to CAN 2.0B ACTIVE specification
鈥?Three Operating modes:
- Legacy mode (full backward compatibility
with existing PIC18CXX8/FXX8
CAN modules)
- Enhanced mode
- FIFO mode or programmable TX/RX buffers
鈥?Message bit rates up to 1 Mbps
鈥?DeviceNet鈩?support
鈥?6 buffers usable as RX and TX Message buffers
鈥?3 Transmit Message buffers with prioritization
鈥?2 Receive Message buffers and 1 Receive Mes-
sage Assembly buffer
鈥?16 full 29-bit Acceptance Filters
鈥?Prioritization of Acceptance Filters
鈥?2 full 29-bit Acceptance Filter Masks
鈥?Programmable wake-up functionality with inte-
grated low-pass filter
鈥?Programmable time-stamp operation for received
messages
鈥?Advanced Error Management features
Special Microcontroller Features:
鈥?100,000 erase/write cycle Enhanced FLASH
program memory typical
鈥?1,000,000 erase/write cycle Data EEPROM memory
typical
鈥?FLASH/Data EEPROM Retention: > 40 years
鈥?Self-programmable under software control
鈥?Priority levels for interrupts
鈥?8 x 8 Single Cycle Hardware Multiplier
鈥?Extended Watchdog Timer (WDT):
- Programmable period from 41 ms to 131s
- 2% stability over V
DD
and Temperature
鈥?Single supply 5V In-Circuit Serial Programming鈩?/div>
(ICSP鈩? via two pins
鈥?In-Circuit Debug (ICD) via two pins
鈥?Wide operating voltage range: 2.0V to 5.5V
錚?/div>
2003 Microchip Technology Inc.
Advance Information
DS39613A-page 1
