PIC17C4X

High-Performance 8-Bit CMOS EPROM/ROM Microcontroller

Devices included in this data sheet:

鈥?/div>

PIC17CR42

PIC17C42A

PIC17C43

PIC17CR43

PIC17C44

PIC17C42鈥?/div>

Pin Diagram

PDIP, CERDIP, Windowed CERDIP

RC0/AD0

RC1/AD1

RC2/AD2

RC3/AD3

RC4/AD4

RC5/AD5

RC6/AD6

RC7/AD7

RB0/CAP1

RB1/CAP2

RB2/PWM1

RB3/PWM2

RB4/TCLK12

RB5/TCLK3

RB6

RB7

OSC1/CLKIN

OSC2/CLKOUT

RD0/AD8

RD1/AD9

RD2/AD10

RD3/AD11

RD4/AD12

RD5/AD13

RD6/AD14

RD7/AD15

MCLR/V

RE0/ALE

RE1/OE

RE2/WR

TEST

RA0/INT

RA1/T0CKI

RA2

RA3

RA4/RX/DT

RA5/TX/CK

PIC17C4X

Microcontroller Core Features:

鈥?Only 58 single word instructions to learn

鈥?All single cycle instructions (121 ns) except for

program branches and table reads/writes which

are two-cycle

鈥?Operating speed:

- DC - 33 MHz clock input

- DC - 121 ns instruction cycle

Program Memory

Device

EPROM

ROM

Data Memory

鈥?TMR2: 8-bit timer/counter

鈥?TMR3: 16-bit timer/counter

鈥?Universal Synchronous Asynchronous Receiver

Transmitter (USART/SCI)

PIC17CR42

232

PIC17C42A

232

PIC17C43

454

PIC17CR43

454

PIC17C44

454

PIC17C42鈥?/div>

232

鈥?Hardware Multiplier

(Not available on the PIC17C42)

鈥?Interrupt capability

鈥?16 levels deep hardware stack

鈥?Direct, indirect and relative addressing modes

鈥?Internal/External program memory execution

鈥?64K x 16 addressable program memory space

Special Microcontroller Features:

鈥?Power-on Reset (POR), Power-up Timer (PWRT)

and Oscillator Start-up Timer (OST)

鈥?Watchdog Timer (WDT) with its own on-chip RC

oscillator for reliable operation

鈥?Code-protection

鈥?Power saving SLEEP mode

鈥?Selectable oscillator options

CMOS Technology:

鈥?Low-power, high-speed CMOS EPROM/ROM

technology

鈥?Fully static design

鈥?Wide operating voltage range (2.5V to 6.0V)

鈥?Commercial and Industrial Temperature Range

鈥?Low-power consumption

- < 5 mA @ 5V, 4 MHz

- 100

碌

A typical @ 4.5V, 32 kHz

- < 1

碌

A typical standby current @ 5V

Peripheral Features:

鈥?33 I/O pins with individual direction control

鈥?High current sink/source for direct LED drive

- RA2 and RA3 are open drain, high voltage

(12V), high current (60 mA), I/O

鈥?Two capture inputs and two PWM outputs

- Captures are 16-bit, max resolution 160 ns

- PWM resolution is 1- to 10-bit

鈥?TMR0: 16-bit timer/counter with 8-bit programma-

ble prescaler

鈥?TMR1: 8-bit timer/counter

鈥燦OT recommended for new designs, use 17C42A.

漏

1996 Microchip Technology Inc.

DS30412C-page 1

This document was created with FrameMaker 4 0 4
