PI74FCT2153CTW Datasheet

  • PI74FCT2153CTW

  • 4-Input Digital Multiplexer

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
PI74FCT153T/253T
(25鈩?Series) PI74FCT2153T/2253T
鈩?/div>
HIGH SPEED CMOS DUAL 4-INPUT MULTIPLEXER
PI74FCT153T/253T
鈩?/div>
(25鈩?Series) PI74FCT2153T/2253T
High-Speed CMOS Dual 4-Input Multiplexer
Product Description:
Product Features:
聲 PI74FCT153T/253T/2153T/2253T is pin compatible with
bipolar FAST聶 Series at a higher speed and lower power
consumption
聲 25鈩?series resistor on all outputs ( FCT2XXX only)
聲 TTL input and output levels
聲 Low ground bounce outputs (25鈩?series only)
聲 Extremely low static power
聲 Hysteresis on all inputs
聲 Industrial operating temperature range: 聳40擄C to +85擄C
聲 Packages available:
聳 16-pin 150 mil wide plastic QSOP (Q)
聳 16-pin 300 mil wide plastic SOIC (S)
聳 16-pin 150 mil wide plastic SOIC (W)
Pericom Semiconductor聮s PI74FCT series of logic circuits are pro-
duced in the Company聮s advanced 0.8 micron CMOS technology,
achieving industry leading speed grades. All PI74FCT2XXX devices
have a built-in 25-ohm series resistor on all outputs to reduce noise
resulting from reflections, thus eliminating the need for an external
terminating resistor.
The PI74FCT153T/253T and PI74FCT2153T/2253T are high-
speed dual 4-input multiplexers. The PI74FCT153T/2153T has
TTL outputs, while the PI74FCT253T/2253T has 3-state outputs.
The output buffers are designed with a power-off disable allowing
聯live insertion聰 of boards when used as backplane drivers.
Logic Block Diagram
E
b
E
a
S
1
S
0
I
0a
I
1a
I
2a
I
3a
I
0b
I
1b
I
2b
I
3b
3-State Enable
on 253 Only
O
a
O
b
1
PS2009A 03/09/96
