PI74ALVCH16344
1-Bit to 4-Bit Address/Driver
with 3-State Outputs
Product Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
PI74ALVCH16344 is designed for low voltage operation
V
CC
= 2.3V to 3.6V
Hysteresis on all inputs
Typical V
OLP
(Output Ground Bounce)
< 0.8V at V
CC
= 3.3V, T
A
= 25擄C
Typical V
OHV
(Output V
OH
Undershoot)
< 2.0V at V
CC
= 3.3V, T
A
= 25擄C
Bus Hold retains last active bus state during 3-State,
eliminating the need for external pullup resistors
Industrial operation at 聳40擄C to +85擄C
Packages available:
聳 56-pin 240 mil wide plastic TSSOP (A)
聳 56-pin 300 mil wide plastic SSOP (V)
Product Description
Pericom Semiconductor聮s PI74ALVCH series of logic circuits are
produced in the Company聮s advanced 0.5 micron CMOS technology,
achieving industry leading speed.
The PI74ALVCH16344 is a 1-bit to 4-bit buffer/driver designed for
2.3V to 3.6V Vcc operation.
The address/driver is designed for applications where four seperate
memory locations must be addressed by a single address.
To ensure the high-impedance state during power up or power down,
OE should be tied to V
CC
through a pullup resistor; the minimum
value of the resistor is determined by the current-sinking capability
of the driver.
The PI74ALVCH16344 has 聯Bus Hold聰 which retains the data
input聮s last state whenever the data input goes to high-impedance
preventing 聯floating聰 inputs and eliminating the need for pullup/
down resistors.
Logic Block Diagram
OE1
1
2
A1
8
6
B14
B11
A5
36
30
B54
OE3
29
34
B51
9
A2
14
13
B21
A6
B24
42
41
B61
37
B64
OE2
28
16
B31
OE4
56
48
B71
A3
15
20
B34
A7
43
44
B74
23
B41
A4
21
27
B44
A8
49
55
B81
51
B84
1
PS8166B
10/19/99
