PI5C6800C
10-Bit BusSwitch with Precharged
Outputs for Live Insertion
Product Features
聲 Near zero propagation delay
聲 5 Ohm switch connection between two ports
聲 Ultra low quiescent power (0.2碌A(chǔ) typ.)
聲 Ideally suited for Notebook Applications
聲 Outputs are precharged by bias voltage to minimize signal
distortion during live insertion
聲 Packages options:
聳 24-pin 150-mil wide plastic QSOP (Q)
聳 24-pin 173-mil wide TSSOP (L)
Product Description
Pericom聮s Semiconductor聮s PI5C series of logic circuits are produced
using the Company聮s advanced submicron CMOS technology,
achieving industry leading performance.
The PI5C6800C is a 10-bit bus switch with low ON-state resistance.
The bus switch creates no additional propagation delay. The device
also precharges the B port to a user-selectable bias voltage (BIASV)
to minimize live-insertion noise.
The switch is turned on by a single enable (ON) input. When ON is
LOW, the switch is on and port A is connnected to port B. When ON
is HIGH, the switch between port A and port B is open and the B port
is precharged to BIASV through the equivalent of a 10-k鈩?resistor.
Logic Diagram
13
Product Pin Configuration
A1
23
B1
A10
14
B10
ON
Truth Table
(1)
Function
Connect
Precharge
Notes:
1. H = High Voltage Level
L = Low Voltage Level
ON
L
H
B1 - B10
A1 - A10
B
IASV
ON
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
GND
1
2
3
4
5
6
7
8
9
10
11
12
24-Pin
L, Q
24
23
22
21
20
19
18
17
16
15
14
13
V
CC
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
BIASV
1
PS8351B
05/02/00
