PI5A4626/PI5A4629
SOT
INY鈩?/div>
Low-Voltage, Single-Supply,
1-Ohm SPST CMOS Analog Switches
Features
鈥?1-ohm max. On-Resistance
鈥?0.15-ohm max. On-Resistance Flatness at +25擄C
鈥?Fast Switching
t
ON
= 50ns max.
t
OFF
= 50ns max.
鈥?+1.8V to +5.5V Single-Supply Operation
鈥?TTL/CMOS-Logic Compatible
鈥?鈥?7dB Off-Isolation at 1MHz
鈥?4nA max. Off-Leakage at +25擄C
鈥?Packaging:
- 5-Pin SOT-23 (T)
Description
PI5A4626/PI5A4629, single-pole/single-throw (SPST) analog
switches that operate from a single +1.8V to +5.5V supply, are
normally open (NO). The PI5A4629 pinout is optimized for the
highest SOT-23 package off-isolation available.
These switches have 1-ohm max On-resistance (R
ON
), with 0.12-
ohm max R
ON
flatness over the analog signal range when powered
from a +5V supply. Leakage currents are 0.5nA and fast switching
times are less than 50ns. They are packaged in a compact 5-pin
SOT-23 package.
Applications
鈥?Cellular Phones 鈥?Communications Circuits
鈥?Battery-Operated Equipment 鈥?DSL Modems
鈥?Audio and Video Signal Routing 鈥?PCMCIA Cards
Pin Description
Pin
4626
1
2
3
4
5
4629
2
4
3
1
5
Name
CO M
NO
GND
IN
V+
Function
Analog Switch, Common
Analog Switch, Normally Open
Ground
Digital Control Input
Positive Supply Voltage
Functional Block Diagrams/Pin Configurations
Top Views
COM
1
5
V+
IN
1
5
V+
NO
2
PI5A4626
GND
3
COM
2
PI5A4629
4
IN
GND
3
4
NO
Note:
NO, NC, and COM pins are identical and interchangeable. Any pin may
be considered as an input or an output; signals pass
Switches shown for Logic 鈥?鈥?input.
Truth Table
Input
LOW
HIGH
Switch State
PI5A4626 / PI5A4629
O FF
ON
1
PS8641A
06/27/04
