鈥?/div>
Small MSOP-8 package minimizes board area
Description
The PI5A126/PI5A127 are dual SPST (single-pole single-throw)
analog switches designed for single supply operation.
These high-precision devices are ideal for low-distortion audio,
video, signal switching and routing.
The PI5A126 is a normally open (NO) switch. The switch is open
when IN is LOW. The PI5A127 is a normally closed (NC) switch.
Each switch conducts current equally well in either direction
when on. When off, they block voltages up to V+.
These switches are fully specified with +5V and +3.3V supplies.
With +5V, they guarantee <10 -ohm ON-resistance. On-resistance
matching between channels is within 2 ohms. On-resistance flat-
ness is less than 5 ohms over the specified range. These switches
also guarantee fast switching speeds (t
ON
< 20ns).
These products are available in 8-pin SOIC and MSOP plastic
packages for operation over the industrial temperature range
(鈥?0
o
C to +85
o
C).
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Audio, Video Switching and Routing
Battery-Powered Communication Systems
Computer Peripherals
Telecommunications
Portable Instrumentation
Mechanical Relay Replacement
Cell Phones
PDAs
Functional Diagrams, Pin Configurations and Truth Tables
Top View
Switches shown for logic 鈥?鈥?input
Logic
1
0
PI5A126
ON
O FF
PI5A127
O FF
ON
1
PS8328C
01/12/01
